Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Image Sensor Type:
Imager
Maximum Scan Resolution:
7.50 mil
Depth of Field:
- 1.9" - 12.2"@7.5mil - Code 39
- 0.6" - 21.4"@13mil - UPC
- 0.6" - 29.5"@20mil - Code 39
- 2.7" - 8.9"@6.7mil - PDF417
- 2.8" - 10.3"@10mil - Data Matrix
- 0.8" - 19.5"@20mil - QR
Scanner Range:
Extended Range
Scanning Distance:
19.50"
Reading Angle (Skew):
65°
Reading Angle (Pitch):
45°
Motion Tolerance:
240 in/s
Maximum Ambient Light:
100000 lux
Drop Specification:
Designed to withstand 50 2 m (6.5´) drops to concrete at -20°C
Minimum Print Contrast:
20%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Maximum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (PDF417):
6.7 mil
