APC SUM3000RMXLI2U UPS

APC Back-UPS Series - APC Smart-UPS XL 3000VA Rack Mountable/Tower - 3000VA/2850W - 3.5 Minute Full Load - 7 x IEC 320-C13 - Battery/Surge-protected, 1 x IEC 320-C19 - Battery/Surge-protected, 4 x - Battery/Surge-protected

Automatic internal bypass - Pure static bypass switch without bridging contactor securing a fast and reliable transfer to and from bypass, rated for 125% nominal load.
Modular design - Enables IT projects that were previously infeasible or cost-prohibitive.
Rack/Tower convertible - Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
USB connectivity - Provides management of the UPS via a USB port (not available on all models).

Need a different version? See all APC Back-UPS Series Accessories

Chat Now for Qty Discount

Add to Quote

$4,993.97

Overview

Full specifications (PDF)

APC Back-UPS Series Accessory Model Overview

An Back-UPS Series instantly switches your computer to emergency battery backup power and allows you to work through brief power outages or to shut down your system in the event of an extended outage. High-performance surge suppression protects your computer from electrical noise and damaging power surges - even lightning.

APC SUM3000RMXLI2U UPS Overview

APC Smart-UPS XL 3000VA protects your data by supplying reliable, network-grade power with scalable run-time in tower and rack mount form factors. With optional, matching battery packs, run-time can be easily extended and optimized for the application. APC understands long run-time requirements so; Smart-UPS XL's can be configured with up to 10 additional battery packs - for run-times exceeding 24 hours, if necessary. The convergence of voice and data networks is placing higher demands on availability expectations - and the Smart-UPS XL delivers. Voice over Internet Protocol (VoIP), e-commerce, WiFi ("hotspots" , WLAN/ WWAN, and mixed wireless), and data enabled PBX's are a few of the applications driving the need for Smart-UPS XL. APC Smart-UPS XL is also the perfect UPS for fileservers (Intel or UNIX based), minicomputers, Network switches and hubs, ATM's, telecommunications systems and other mission-critical applications requiring longer runtime.

Detailed Specs

Full specifications (PDF)

Technical Information

Plug/Connector Type:

IEC 320-C20

Receptacle Type:

IEC 60320 C19
IEC 60320 C13

Receptacle Detail:

7 x IEC 60320 C19
1 x IEC 60320 C13
4

Number of Battery & Surge Outlets:

Bypass Switch:

Automatic & Manual

Emergency Power OFF:

Optional

Cord Length:

10 ft

Power Description

Load Capacity:

3000 VA/2850 W

Input Voltage:

220 V AC

Output Voltage:

230 V AC
240 V AC

Waveform Type:

Sine Wave

Surge Energy Rating:

490 J

Management

Alarm:

On Battery
Low Battery
Configurable Delay

Battery Management:

Intelligent Battery Management

Controls/Indicators

Status Indicators:

Load Bar-graphs
Battery Bar-graphs
On Line
On Battery
Replace Battery
Overload
Bypass

Interfaces/Ports

Serial Port:

Yes

Network (RJ-45):

Yes

USB:

Yes

Battery Information

Battery Chemistry:

Lead Acid

Backup/Run Time (Full Load):

3.50 Minute

Backup/Run Time (Half Load):

11.90 Minute

Hot Swappable:

Yes

Environmental Conditions

Maximum Operating Temperature:

113°F (45°C)

Thermal Dissipation:

87.92 W

Physical Characteristics

Product Color:

Black

Height:

3.4"

Width:

17"

Depth:

26.7"

Rack Height:

Form Factor:

Rack-mountable

Weight (Approximate):

103 lb

Miscellaneous

Package Contents:

Smart-UPS XL 3000VA Rack Mountable/Tower

CD with software

Rack mounting brackets

Rack mounting support rails

Smart UPS signalling RS-232 cable

USB cable

User manual

Additional Information:

Replacement battery cartridge: 1
Battery Modules Shipped with Unit: 1
Efficiency at full load: 89%
Output Voltage Distortion: Less than 5% at full load
Crest Factor: up to 5:1
Units per Pallet: 8
Adjustable voltage sensitivity
Adjustable voltage-transfer points
Automatic restart of loads after UPS shutdown
Automatic self-test
Boost and Trim Automatic Voltage Regulation (AVR)
Cold-start capable
Disconnected battery notification
Generator compatible
Scalable runtime

Certifications & Standards:

C-tick
CE
EN 50091-2
EN 55022 Class A
EN 61000-3-2
GOST
UL 1449

Environmentally Friendly:

Yes

Warranty

Limited Warranty:

2 Year

Item Numbers

GTIN: 0731304224501, 0731304224570

UPC: 731304224501, 731304224570

EAN: 0731304224501, 0731304224570

UNSPSC: 39121011
