APC SURT1000XLI Accessory

APC Back-UPS Series  -  Smart-UPS RT 1000VA 230V
  • Optimal protection by isolating the equipment from raw utility power
  • Up to 10.2-minute runtime on full load to preserve critical data from power shortage interruptions
  • Offers advanced performance with battery backup
  • Add an unlimited number of external batteries (not included) to meet your desired runtime
Read More
Add to Quote
$2,556.52
APC Back-UPS Series Accessory Model Overview
An Back-UPS Series instantly switches your computer to emergency battery backup power and allows you to work through brief power outages or to shut down your system in the event of an extended outage. High-performance surge suppression protects your computer from electrical noise and damaging power surges - even lightning.
APC SURT1000XLI Accessory Overview
Smart-UPS RT is a family of high preformance UPSs for servers, networking equipment, telecommunication systems, industrial and medical equipment, and other mission-critical applications. Smart-UPS RT UPSs are based on the field-proven, industry-leading Smart-UPS functionality, but features double conversion on-line topology, which delivers tight voltage and frequency regulation, zero transfer time to and from battery, and input power factor correction. While offering advanced performance and high availability features, the Smart-UPS RT can be managed using PowerChute software, as well as an array of SmartSlot accessories. Smart-UPS RT provides battery back up to the load through the use of internal batteries. However, an unlimited number of external battery packs can be added to meet desired levels of runtime. All Smart-UPS RTs and battery packs ship in tower configuration, while easily converting to the 19" rack-mount mode with the addition of an APC Rail Kit.
Technical Information
Plug/Connector Type:
IEC 320-C14
Receptacle Type:
IEC 60320 C13
Receptacle Detail:
  • 6 x IEC 60320 C13
  • 2
Number of Battery & Surge Outlets:
8
Bypass Switch:
Automatic
Emergency Power OFF:
Optional
Transfer Time:
0 ns
Power Description
Load Capacity:
1000 VA/700 W
Input Voltage:
220 V AC
Output Voltage:
230 V AC
Waveform Type:
Sine Wave
Surge Energy Rating:
420 J
Management
Alarm:
  • On Battery
  • Low Battery
  • Overload
Battery Management:
Intelligent Battery Management
Controls/Indicators
Status Indicators:
LED status display with load and battery bar-graphs and On Line, On Battery, Replace Battery, Overload and Bypass Indicators.
Interfaces/Ports
Serial Port:
Yes
Total Number of Expansion Slots:
1
Battery Information
Battery Characteristics:
Spill-proof, Maintenance-free
Battery Chemistry:
Lead Acid
Backup/Run Time (Full Load):
10.20 Minute
Backup/Run Time (Half Load):
24.40 Minute
Typical Battery Recharge Time:
3 Hour
Hot Swappable:
Yes
Environmental Conditions
Maximum Operating Temperature:
122°F (50°C)
Sound Emission (A-Weighted):
50 dB(A)
Thermal Dissipation:
70.04 W
Physical Characteristics
Product Color:
Black
Height:
3.4"
Width:
17"
Depth:
19"
Form Factor:
Tower
Weight (Approximate):
50.60 lb
Miscellaneous
Package Contents:
  • Smart-UPS RT 1000VA
  • CD with software
  • Smart UPS signalling RS-232 cable
  • User manual
  • Additional Information:
    • Automatic Self Test
    • Automatic Shutdown
    • Automatic Voltage Regulation (AVR)
    • Built-in automatic bypass
    • Cold-start
    • Compact and Lightweight
    • Designed and manufactured under ISO9001 / ISO14001 certification
    • Downloadable Firmware
    • Early-warning Problem Notification
    • Faster Recharge Time
    • Generator Compatible
    • Input Power Factor Correction
    • Lightning and Surge Protection
    • Load Meter
    • Multi-colored Flashing LED
    • Network-grade line conditioning
    • Overload Handling Capacity
    • Programmable Frequency
    • Scalable Run Time
    • Surge Protection
    • Temperature Compensated Battery Charging
    • Terminal Mode Programmability
    • Unattended Safe & Graceful Shutdown
    • Up to 90% efficiency
    • Web Management
    • Wide input voltage range
    • Multiple Output Voltages
    • Configurable for 220 : 230 or 240 nominal output voltage
    Certifications & Standards:
    • C-tick
    • CE
    • EN 50091-1
    • EN 50091-2
    • EN 55022 Class A
    • EN 60950
    • EN 61000-3-2
    • GOST
    • PCBC
    • VDE
    • UL 1449
    Environmentally Friendly:
    Yes
    Warranty
    Limited Warranty:
    2 Year
    Item Numbers
    GTIN: 7313042054188
    EAN: 7313042054188
    UNSPSC: 39121011
    Get help from a Barcoding Expert!

    What type of Barcode are you scanning?

    The APC SURT1000XLI Accessory is also known as APC-SURT1000XLI
