Asus H7604JI-DS96T Workstation PC

The Asus H7604JI-DS96T Workstation PC has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Asus ProArt Studiobook 16  -  Workstation PCs, Asus ProArt Studiobook 16, OLED 16" Touchscreen, Mobile Workstation, 3.2K, 3200 x 2000, Intel Core i9 13th Gen i9-13980HX Tetracosa-core (24 Core) 2.20 GHz, 32 GB Total RAM, 1 TB SSD, Mineral Black, Intel Chip, Windows 11 Home, NVIDIA GeForce RTX 4070 with 8 GB, Intel UHD Graphics, Tru2Life, Front Camera/Webcam, IEEE 802.11ax Wireless LAN Standard
  • 16'' OLED 3.2K (3200 x 2000) 16:10 touch display laptop; 120Hz refresh rate with 0.2ms response time; 100% DCI-P3 color gamut; Pantone validated color accuracy; 500 nits; Delta E <2; with 4096 pressure-level MPP 2.0 stylus support (Stulys included with purchase)
  • Intel® Core™ i9-13980HX Processor 2.2 GHz (36MB Cache, up to 5.6 GHz, 24 cores, 32 Threads) with Windows 11 Home
  • NVIDIA® Geforce RTX™ 4070 Laptop GPU with 8GB GDDR6 VRAM - RTX Studio Ready
  • Fast storage and memory (upgradable) featuring 1TB M.2 NVMe™ PCIe® 4.0 Performance SSD and 32GB DDR5 SO-DIMM Memory
  • US MIL-STD 810H military-grade standard
  • Intuitive ASUS Dial: change brush size, saturation and more with intuitive ASUS dial to streamline workflow. Function settings are customizable in ProArt Creator Hub, learn more on ASUS website for details
  • Extensive connectivity with HDMI 2.1 FRL, RJ45 Gigabit Ethernet, 2X USB 3.2 Gen 2 Type A, 2x Thunderbolt™ 4 support display/power delivery, SD express 7.0 card reader, 3.5mm Combo Audio Jack and 1x Headphone/Headset (*USB Transfer speed may vary. Learn more at ASUS website)
  • Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5
  • 0.94" thin profile at portable 5.29lbs
  • Backpack and Stylus (ASUS Pen 2.0 SA203H-MPP2.0 support) are included with purchase
Read More
Add to Quote
Asus Parts Laptop Model Overview
Products and parts from ASUS.
Asus H7604JI-DS96T Workstation PC Overview

Born for Creative Pros

The new ProArt Studiobook 16 OLED is a powerful mobile workstation that exceeds all expectation and goes far beyond the extraordinary. Its unstoppable 13th Gen Intel&reg;Core&trade;i9 HX processor, up to NVIDIA&reg;GeForce RTX&trade;4070 graphics, vast amounts of memory and ultrafast storage will supercharge your content creation workflow and let your imagination to do what it does best. The certified color-accurate 16-inch 3.2K 120 Hz OLED touchscreen will do full justice to your creative vision, and you'll enjoy unrivaled precision control of your apps with the large, stylus-compatible haptic touchpad and intuitive ASUS Dial rotary control. Take your creativity to the next level with ProArt Studiobook 16 OLED.

PERFORMANCE | More power to you on the go

Performance is the essence of ProArt Studiobook 16 OLED, putting desktop-grade content-creation capabilities in a take-anywhere package. The 13th Gen Intel Core i9 processor makes light work of compute-intensive workloads, and it is teamed with a professional-grade NVIDIA GeForce RTX 4070 GPU, two of the latest, fastest SSDs, and up to 64 GB of high-performance RAM. Finally, there's a mobile workstation that truly deserves the name.

CPU | Tackle the heaviest workloads

Even the heaviest compute-intensive workloads are no problem for the latest 13th Gen Intel Core i9-13980HX processor. It has an unprecedented 24 cores for effortless multithreading performance, a Turbo Boost speed of up to 5.6 GHz, and its 100 W maximum TDP gives makes light work of CPU-heavy tasks, so you can enjoy desktop-grade performance wherever you are.

GPU | Create the future, fast

Creating the future is easy when you have the awesome graphics power of the NVIDIA GeForce RTX 4070 Laptop GPU on tap. Built with the latest Ada Lovelace architecture, it enables ultrarealistic ray-traced graphics, cutting-edge AI computing and programmable shading - lifting all visuals to the next level. In short, no matter how heavy your demands, from product design and model rendering to video encoding, the RTX 4070 Laptop GPU delivers all the performance needed for top-end content creation. ProArt Studiobook 16 OLED is also supplied with NVIDIA Studio Drivers, ensuring every creative task is able to perform at its best.

THERMAL | It's cool to be quietThe advanced ASUS IceCool Pro thermal technology in ProArt Studiobook 16 OLED gives it the edge when it comes to performance and quietness. Liquid metal thermal materials on the CPU, five heat pipes and larger 102-blade dual fans ensure optimum cooling performance. The new per-key keyboard lighting with air-intake design also helps maximize airflow, too. All this technology helps keep noise levels below 40 dBA in Standard cooling mode, or you can unleash the full 150 W combined CPU/GPU TDP whenever you need to. Cool, quiet, and powerful: what more do you need?

Processor
Processor Manufacturer:
Intel
Processor Type:
Core i9
Processor Generation:
13th Gen
Processor Model:
i9-13980HX
Processor Core:
Tetracosa-core (24 Core)
Processor Speed:
2.20 GHz
Maximum Turbo Speed:
5.60 GHz
Chipset
Chipset Manufacturer:
Intel
Memory
Total Installed System Memory:
32 GB
Maximum Supported System Memory:
64 GB
System Memory Technology:
DDR5 SDRAM
System Memory Speed:
5200 MHz
System Memory Form Factor:
SoDIMM
Installed Slot Memory:
32 GB
Total Number of Memory Slots:
2.0
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
1 TB
SSD Form Factor:
M.2
Display & Graphics
Screen Size:
16"
Display Screen Type:
OLED
Display Screen Technology:
Tru2Life
Standard Refresh Rate:
120 Hz
Screen Mode:
3.2K
Screen Resolution:
3200 x 2000
Touchscreen:
Yes
Graphics Controller Manufacturer:
  • NVIDIA
  • Intel
Graphics Controller Model:
  • GeForce RTX 4070
  • UHD Graphics
Graphics Memory Capacity:
8 GB
Graphics Memory Technology:
  • GDDR6
  • DDR5 SDRAM
Graphics Memory Accessibility:
  • Dedicated
  • Shared
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11ax
Ethernet Technology:
Gigabit Ethernet
Bluetooth:
Yes
Built-in Devices
Front Camera/Webcam:
Yes
Infrared Camera:
Yes
Interfaces/Ports
HDMI:
Yes
Total Number of USB Ports:
2
Number of USB 3.2 Gen 2 Type-A Ports:
2
Number Of Ethernet Ports:
1
Network (RJ-45):
Yes
Number of Thunderbolt 4 Ports:
2
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Home
Input Devices
Keyboard Backlight:
Yes
Battery Information
Number of Cells:
4-cell
Power Description
Maximum Power Supply Wattage:
240 W
AC Adapter Frequency:
  • 50 Hz
  • 60 Hz
Physical Characteristics
Product Color:
Mineral Black
Height:
0.94"
Width:
14"
Depth:
10.7"
Weight (Approximate):
5.29 lb
Miscellaneous
Package Contents:
  • ProArt Studiobook 16 OLED H7604JI-DS96T Mobile Workstation
  • Lithium Ion Battery
  • AC Adapter
  • Backpack
  • Stylus
Features:
  • Eye Care
  • Cortana
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • REACH
Warranty
Limited Warranty:
1 Year
Additional Warranty Information:

1 year manufacturer's limited warranty

Item Numbers
UNSPSC: 43211503
