AudioCodes M800-12S-12L-P Data Networking

The AudioCodes M800-12S-12L-P Data Networking has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
AudioCodes Mediant 800 - AudioCodes Mediant 800 Multi-Service Business Gateway - 1 x RJ-45 - 4 x FXS - 4 x FXO - USB - PoE Ports - Gigabit Ethernet - 1U High

Need a different version? See all AudioCodes Mediant 800 Data Networkings

Discontinued Need Assistance?
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
AudioCodes M800-12S-12L-P Data Networking
AudioCodes M800-12S-12L-P Data Networking
AudioCodes M800-12S-12L-P Data Networking AudioCodes M800-12S-12L-P Data Networking
Full specifications (PDF)
AudioCodes Mediant 800 Data Networking Model Overview
The Mediant 800 is an all-in-one, Multi-Service Business Gateway solution, designed to provide converged Voice & Data services for small-to-mid size business (SMB) customers, and to form a well-managed point of demarcation for service providers. The Mediant 800 is based on AudioCodes' VoIPerfectHD best-of-breed Media Gateway technology, integrating a variety of communication functions into a single platform to support fundamental services, such as VoIP mediation, Data Routing, WAN access, Voice & Data security, survivability, and third party value-added services applications. These services allow smooth connectivity to cloud services.
AudioCodes M800-12S-12L-P Data Networking Overview

Best-of-Breed Small-to-mid-Size Enterprise Class Media Gateway

AudioCodes Mediant 800 MSBG is built upon a highly interoperable VoIP Media Gateway that can be delivered in several pre-defined configurations, supporting a single E1/T1/J1 trunk, up to 4 BRI ports (8 calls) or up to 12 analog (FXS/FXO) ports. In addition, the Mediant 800 MSBG provides enhanced dialing plans and voice routing capabilities along with SIP to SIP mediation, allowing business customers to enjoy the benefits of SIP Trunking services, IP Centrex connectivity, Unified Communications, as well as flexible PSTN and legacy PBX connectivity to VoIP.

Full specifications (PDF)
Interfaces/Ports
Serial Port:
Yes
PoE (RJ-45) Port:
Yes
USB:
Yes
Management Port:
No
Number of PoE (RJ-45) Ports:
12
Number of Network (RJ-45) Ports:
1
Number of FXS (RJ-11) Ports:
4
Number of FXO (RJ-11) Ports:
4
Network & Communication
Carrier Supported:
T-carrier
Ethernet Technology:
Gigabit Ethernet
Network Standard:
10/100/1000Base-T
Wireless Specifications
Wireless LAN:
No
Management & Protocols
Voice Codec:
  • T.38
  • G.711
  • G.722
  • G.723.1
  • G.165
  • G.168
  • G.729a
Memory
Standard Memory:
1000 MB
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
Physical Characteristics
Form Factor:
Rack-mountable
Compatible Rack Unit:
1U
Width:
13.6"
Depth:
12.6"
Miscellaneous
Package Contents:
  • Mediant 800 Multi-Service Business Gateway
  • 1 x AC Power Supply
Certifications & Standards:

Safety and EMC:

  • UL60950-1
  • EN60950-1
  • CB
  • EN55024
  • EN55022 Class A
  • EN61000-3-2
  • EN61000-3-3
  • EN300 386
  • FCC 47 Part 15 Class A

Telecommunication:

  • TIA/EIA-IS-968
  • ETSI ES 203 021
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • China RoHS
  • WEEE
  • REACH
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43222605
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The AudioCodes M800-12S-12L-P Data Networking is also known as AUC-M800-12S-12L-P
