Axis 01633-001 Data Networking Overview
AXIS T8504-R Industrial PoE Switch is a 4-port managed industrial PoE++ Gigabit switch. In addition, the switch is equipped with two RJ45 and two SFP data ports that allows for extra devices to be connected.
For high demanding installations
The ruggedized industrial switch is developed for challenging environments, when mounted inside a surveillance cabinet. It is designed to withstand shock, vibrations and temperatures from -40 °C to 75 °C (-40 °F to 167 °F), making it perfect for high demanding installations such as alongside highways and tunnels.
Easy to install and configure
AXIS T8504-R Industrial PoE Switch, is easy to install by using standard Axis tools as AXIS IP Utility and AXIS Device Manager. AXIS T8504-R also comes with an individual password, an easy to use setup wizard, and a comprehensive set of configuration tools such as an integrated DHCP server for automatic assignment of IP addresses. It also allows for even more advanced network configuration such as Rapid Ring Protection Protocol, VLAN, QoS, Security, and Spanning tree to further optimize the total solution.
Total overview with unique user interface
AXIS T8504-R uses the same intuitive administrator interface as AXIS T85 PoE Network Switch Series .The unique web graphic user interface offers a graphic topology for easy overview of all devices in the system. The graphic user interface provides information, status and notifications about connected devices. It allows for management of all connected devices, reboot of cameras in the system, monitoring of network traffic, cable diagnostics and much more.
Technical Information
Power Description
Maximum Output Power:
240 W
Interfaces/Ports
Input Ports:
- 2 x 10/100/1000Base-T
- 2 x SFP
Output Ports:
4 x 10/100/1000Base-T
Physical Characteristics
Product Color:
Black
Form Factor:
Cabinet Mountable
Height:
5.3"
Width:
2.4"
Depth:
5.1"
Weight (Approximate):
1.32 lb
Miscellaneous
Compatibility:
Devices:
Bridges
Bridges
- C8033
Desktop Terminals
- S9101
- S9201
Door Controllers
- A1001
- A1601
Door Stations
- A8105-E
Fixed Cameras
- M1065-L
- M1124
- M1124-E
- M1125
- M1125-E
- M1145-L
- M2025-LE
- M2026-LE Mk II
- P1214
- P1214-E
- P1224-E
- P1244
- P1245
- P1254
- P1264
- P1265
- P1275
- P1364
- P1364-E
- P1365 Mk II
- P1365-E Mk II
- P1367
- P1367-E
- P1368-E
- P1435-LE
- P8804
- Q1615 Mk II
- Q1615-E Mk II
- Q1645
- Q1645-LE
- Q1647
- Q1647-LE
- Q1659
- Q1765-LE
- Q1765-LE PT Mount
Fixed Dome Cameras
- M3015
- M3016
- M3024-LVE
- M3025-VE
- M3026-VE
- M3027-PVE
- M3037-PVE
- M3044-V
- M3045-V
- M3046-V
- M3047-P
- M3048-P
- M3057-PLVE
- M3058-PLVE
- M3104-L
- M3104-LVE
- M3105-L
- M3105-LVE
- M3106-L Mk II
- M3106-LVE Mk II
- P3224-LV Mk II
- P3224-V Mk II
- P3225-LV Mk II
- P3225-LVE Mk II
- P3225-V Mk II
- P3225-VE Mk II
- P3227-LV
- P3227-LVE
- P3228-LV
- P3228-LVE
- P3235-LV
- P3235-LVE
- P3367-V
- P3367-VE
- P3374-LV
- P3374-V
- P3375-LV
- P3375-LVE
- P3375-V
- P3375-VE
- P3707-PE
- P3807-PVE
- P3904-R Mk II
- P3905-R Mk II
- P3905-RE
- P3915-R Mk II
- P9106-V
- Q3515-LV
- Q3515-LVE
- Q3517-LV
- Q3517-LVE
- Q3517-SLVE
- Q3518-LVE
- Q3527-LVE
- Q3615-VE
- Q3617-VE
- Q3708-PVE
- Q3709-PVE
- Q8414-LVS
I/O relay modules
- A9161
- A9188
- A9188-VE
Illuminators
- T90D20 PoE IR-LED
- T90D25 PoE W-LED
- T90D30 PoE IR-LED
- T90D35 PoE W-LED
- F34 Main Unit
- F34 Surveillance system
- F41 Main Unit
- F44 Dual Audio Input
- FA54 Main Unit
PTZ Cameras
- M5054
- M5055
- M5065
- M5525-E
- P5414-E
- P5415-E
- P5624-E Mk II
- P5635-E Mk II
- Q6000-E Mk II
- Q6054 Mk III
- Q6054-E Mk III
- Q6055
- Q6055-E
- Q6124-E
- Q6125-LE
- Q6128-E
- Q6155-E
- Q8641-E
- Q8642-E
- Q8685-E
- Q8685-LE
- Q8741-E
- Q8741-LE
- Q8742-E
- Q8742-LE
Positioning Units
- T99A10 Positioning Unit 24 V AC/DC
- T99A11 Positioning Unit 24 V AC/DC
Radar Detectors
- D2050-VE
TAA Compliant:
Yes
NDAA Compliant:
Yes
Item Numbers
GTIN:
7331021066199
EAN:
7331021066199
UNSPSC:
39121004
