Full specifications (PDF)
Recording Formats:
Full HD
HD Recording:
Yes
Axis P12 Series Security Camera Model Overview
Axis P12 Series Network Cameras is a series of uniquely designed cameras for exceptionally discreet surveillance. The series comprises three models; two pinhole models, Axis P12 Series cameras are ideal for indoor installations, and Axis P1214-E, which is an IP66-rated model that can be installed both indoors and outdoors.
Axis 0926-001 Security Camera Overview
AXIS P1245 is a cost - effective complete modular camera with HD TV 1 080p resolution, ideal for discreet indoor surveil- lance in stores and banks. It can be installed in tight places or flush - mounted in a wall, ceiling, or metal panel with only a small hole visible for the lens, suitable in, for example, A TMs or vending machines. Equipped with WDR - Foren- sic Capture, enables the camera to handle scenes with strong variations in light. AXIS P1245 comes with a mounting bracket and an 8 meter (26 feet) detachable cable.
- HDTV 1080p resolution
- WDR - For ensic Capture
- 111° horizontal field of view
- Axis Zipstream
- Power over Ethernet
Technical Information
Display & Graphics
Image Sensor Type:
RGB CMOS
Color Supported:
Color
Field of View:
Horizontal field of view111 ° Vertical field of view61 °
Effective Camera Resolution:
2 Megapixel
Video
Video Formats:
- H.264
- MJPEG
- MPEG-4 AVC
- Zipstream
- H.264B
- H.264H
- H.264M
- H.264 (MPEG-4 Part 10/AVC)
- H.264 HP
Maximum Video Resolution:
1920 x 1080
Maximum Frame Rate:
30 fps
Lens
Lens Type:
Fixed
Maximum Focal Length:
2.80 mm
Lens Included:
Yes
Lens Mount Type:
M12-mount
Maximum Aperture:
f/2
Exposure
Shortest Shutter Speed:
1/32500 Second
Longest Shutter Speed:
2 Second
Network & Communication
Connectivity Technology:
Wired
Remote Management:
Yes
Storage
Storage Type:
Memory Card
Interfaces/Ports
Network (RJ-45):
Yes
Power Description
Power Source Type:
PoE
Physical Characteristics
Mount Type:
- Wall Mount
- Ceiling Mount
- Flush Mount
- Bracket Mount
Product Color:
- Black
- White
Height:
1.8"
Width:
0.6"
Depth:
4.3"
Weight (Approximate):
2.54 oz
Environmental Conditions
Minimum Operating Temperature:
-4°F (-20°C)
Maximum Operating Temperature:
122°F (50°C)
Operating Humidity:
85%
Miscellaneous
Features:
- Auto Gain Control
- Automatic White Balance
- Motion Detection
- Privacy Masking
- Wide Dynamic Range
- HTTPS Encryption
Indoor/Outdoor:
Indoor
Package Contents:
- P1245 Network Camera
- Installation Guide
- Windows decoder 1-user license AXIS F8206 Pinhole Mounting Bracket 8-m (26 ft) black cable
Country of Origin:
Thailand
NDAA Compliant:
Yes
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN:
0136393456770, 7331021052826
UPC:
136393456770
EAN:
0136393456770, 7331021052826
UNSPSC:
46171610
