Black Box ACU5800A Accessory

Black Box - Black Box Dual-Head DisplayPort KVM Extender over CATx - 1 Computer(s) - 1 Remote User(s) - 492 ft Range - 4K - 4096 x 2160 Maximum Video Resolution - 6 x Network (RJ-45) - 6 x USB - DisplayPort

Extends DisplayPort, USB 2.0, USB HID, and digital/analog audio over CATx cables
Extend 3840x2160 4K at 30Hz or 2560x1600 dual-link video up to 330 ft. (100 m)
Extend 1920x1080 dual-head video up to 492 ft. (150 m)
Support for USB keyboards, mice, tablets, and touchscreens
USB 2.0 Hi-Speed for mass storage devices
Use one CATx cable for basic performance and two CATx cables for highest performance
Includes intelligent EDID management
HD quality analog audio
Receiver supports DisplayPort Dual Mode

Need a different version? See all Black Box Parts Products

Chat Now for Qty Discount

Add to Quote

$3,265.35

Detailed Specs

Technical Information

Connectivity Technology:

Wired

Number of Computers Supported:

Number of Remote Users Supported:

Maximum Operating Distance:

492 ft

Video

Graphic Mode:

Maximum Video Resolution:

4096 x 2160

Interfaces/Ports

Network (RJ-45):

Yes

USB:

Yes

DisplayPort:

Yes

Number of Network (RJ-45) Ports:

Number of USB Ports:

Power Description

Input Voltage:

120 V AC
230 V AC
5 V DC

Input Voltage Range:

100-240 VAC

Power Consumption:

20 W

Frequency:

50 Hz
60 Hz

Physical Characteristics

Transmitter Height:

1.76"

Transmitter Width:

7.92"

Transmitter Depth:

4.62"

Receiver Height:

1.76"

Receiver Width:

7.92"

Receiver Depth:

4.62"

Transmitter Weight (Approximate):

1.43 lb

Receiver Weight (Approximate):

1.43 lb

Miscellaneous

Package Contents:

1 x Transmitter
1 x Receiver
2 x 5 VDC, 4 Amp Power Supplies
2 x USB Type A to B Cables (6-Ft Each)
1 x Display-Port Cable, (6.6-ft.)
2 x 3.5-mm Audio Cables (10-Ft.)
1 x DB9 Female To RJ-45 Flash Upgrade Cable
2 x US Power Cords
1 X Safety Information Sheet
2 X Sets Of Four Rubber Feet

Certifications & Standards:

TAA

Platform Supported:

PC
Mac
Sun
Linux
Unix

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Country of Origin:

United Kingdom

Warranty

Limited Warranty:

2 Year

Item Numbers

GTIN: 0822088075400, 0822088075417

UPC: 822088075400, 822088075417

EAN: 0822088075400, 0822088075417

UNSPSC: 43211603
