Black Box LBH100A-H-SC-12 Wireless Switch

The Black Box LBH100A-H-SC-12 Wireless Switch has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Black Box  -  Black Box Fast Ethernet Hardened Media Converter Switch - 1 x SC Duplex , 2 x RJ-45 - 100Base-X, 10/100Base-TX - Rack-mountable, External

  • One 100-Mbps fiber port and two 10-/100-Mbps RJ45 switch ports.
  • Fiber interface is MM, SC, 2km range.
  • Suitable for dusty or dirty environments with a temperature range between -13 and +140º F (-25 to +60º C).
  • 12-VDC power input.
  • Includes panel mount kit.
Read More
Need a different version? See all Black Box Parts Products
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Discontinued Need Assistance?
Black Box LBH100A-H-SC-12 Wireless Switch
Black Box LBH100A-H-SC-12 Wireless Switch
Interfaces/Ports
Total Number of Ports:
3
Network (RJ-45):
Yes
Number of Network (RJ-45) Ports:
2
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
  • Optical Fiber
  • Twisted Pair
Fiber Mode Supported:
Multi-mode
Fiber Optic Wavelength:
850 nm
Maximum Distance Supported:
1.24 Mile
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Technology:
  • 100Base-X
  • 10/100Base-TX
Power Description
Power Source:
DC
Physical Characteristics
Form Factor:
  • Rack-mountable
  • External
Height:
3.5"
Width:
3"
Depth:
1"
Weight (Approximate):
4.80 oz
Miscellaneous
Additional Information:
  • Internal terminal block for 12-VDC power plus jack for AC power supply

Features:

  • Rail-mountable
  • Supports auto-negotiation
  • Suitable for dusty or dirty environments
  • Supports both half- and full-duplex operation
Country of Origin:
United States
TAA Compliant:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0641676611765, 0787416059661, 0822088104650
UPC: 641676611765, 787416059661, 822088104650
EAN: 0641676611765, 0787416059661, 0822088104650
UNSPSC: 43201553
