Black Box VSC-HDMI-SDI Products

Black Box - Black Box HDMI to 3G-SDI/HD-SDI Converter - Functions: Video Conversion - 1920 x 1080 - NTSC, PAL - Wall Mountable

Converts an HDMI® signal for output on two serial digital interface devices.
Supports 3G-SDI, HD-SDI, and SD-SDI output on two coax BNC connectors.
Purely digital, real-time conversion, with no loss of video or audio.
Ideal for connecting a camera or other source with HDMI output to professional SDI video equipment.
Can be combined with our VSC-SDI-HDMI converter to extend HDMI over coax.
Supports loopout and daisychaining via one of the coax connectors.
Works with 1080p HDMI video and Deep Color resolutions.

Need a different version? See all Black Box Parts Products

Chat Now for Qty Discount

Add to Quote

$253.88

Detailed Specs

Technical Information

Functions:

Video Conversion

Video Signal Format:

NTSC
PAL

Maximum Resolution:

1920 x 1080

Maximum Frame Rate:

60 fps

Frequency Range:

50Hz to 60Hz

Maximum Data Transfer Rate:

23.76 Gbit/s

Digital Signal:

Yes

HDCP Supported:

Interfaces/Ports

HDMI:

Yes

Number of HDMI Inputs:

SDI:

Yes

Number of SDI Outputs:

Physical Characteristics

Form Factor:

Wall Mountable

Height:

1.2"

Width:

3.1"

Depth:

3.3"

Weight (Approximate):

1.70 lb

Miscellaneous

Package Contents:

HDMI to 3G-SDI/HD-SDI Converter
AC Power Adapter
Wallmount Ears
Screws
User Manual

Certifications & Standards:

Environmentally Friendly:

Yes

Environmental Certification:

RoHS

Country of Origin:

Taiwan

TAA Compliant:

Yes

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 0822088062370

UPC: 822088062370

EAN: 0822088062370

UNSPSC: 43211608
