Bosch CNMC2SFP Products

Bosch - Dual 10/100/1000Mbps Multi-Rat Media Converter, 100FX/1000FX

IEEE 802.3 compliant
Designed for installation in harsh out-of-plant/ unconditioned industrial or roadside operating environments (-40 º to +75 ºC ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
Status indicating LEDs provide rapid indication of critical operating parameters.
Supports Jumbo Frames
Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events.
ComFit standard form factor is interchangeable between stand-alone or rack mount use.
Uses customer-installed ComNet SFPs for compatibility with a wide range of optical fibers, optical connector types, and optical transmission distances (SFPs ordered separately).
Compact form-factor saves space in those installations where space may be at a premium.
Electrical port supports both auto-negotiation of data speeds and automatic MDI/MDI-X crossover for full and half-duplex operation.
Standard ComFit models are hot-swappable.

Need a different version? See all Bosch Parts Accessories

Chat Now for Qty Discount

Add to Quote

$1,774.66

Overview

Bosch Parts Accessory Model Overview

Products and parts from Bosch.

Bosch CNMC2SFP Products Overview

The ComNet Ethernet CNMC2+1SFP electrical-to-optical Ethernet media converters accept two 10/100 or 1000 Mbps electrical inputs and converts this to a single 100 or 1000 Mbps optical output (selected by a DIP switch) and the 100/1000 Mbps optical input back to the 10/100/1000 Mbps electrical output. "Auto-Negotiating" is supported on the copper interface side. These devices use either one or two optical fibers, depending upon the selection of sold-separately SFP optical module. The ComNet exclusive Demux feature allows for port isolation, replicating two media converters over one fiber. The ComNet exclusive Mux feature prevents network video flooding of multicast traffic with DIP switch selection of the fiber port as a dedicated uplink path. The CNMC2+1SFP series can be powered by wide range of AC or DC input power supplies.

Detailed Specs

Interfaces/Ports

Total Number of Ports:

Network (RJ-45):

Yes

Number of Network (RJ-45) Ports:

Media & Performance

Media Type Supported:

Twisted Pair
Optical Fiber

Maximum Distance Supported:

74.56 Mile

I/O Expansions

Number of Total Expansion Slots:

Expansion Slot Type:

SFP

Number of SFP Slots:

Network & Communication

Ethernet Technology:

Gigabit Ethernet

Network Technology:

10/100/1000Base-TX
1000Base-FX

Power Description

Power Source:

Power Supply

Physical Characteristics

Form Factor:

Rail-mountable
Standalone
Rack-mountable

Height:

1.1"

Width:

5.3"

Depth:

6.1"

Miscellaneous

Package Contents:

ComFit Dual 10/100/1000Mbps Ethernet Media Converter with IEEE 802.3at 30W PoE+
DC Plug-in Power Supply, 90-264 VAC, 50/60 Hz

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Country of Origin:

United States

Warranty

Limited Warranty:

Lifetime

Item Numbers

UNSPSC: 43201553
