Bosch CNMCSFPPoE/M Products

Bosch - 10/100/1000Mbps Multi-Rate Med Converter, 100FX/1000FX Select

Full-duplex transmission of 10/100/1000 Mbps Ethernet - 10/100/1000BASE-TX electrical port, 1000BASE-FX or 100BASE-FX optical port when used with suitable ComNet SFPs
IEEE 802.3 compliant
10/100/1000 BASE-TX port supports auto-negotiation and automatic MDI/MDI-X crossover for full and half-duplex operation
Uses customer-installed ComNet SFPs for compatibility with a wide range of optical fibers, optical connector types, and optical transmission distances of up to 120 km
Designed for installation in harsh out-of-plant/unconditioned industrial or roadside operating environments (-40o to +75oC ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
Voltage transient protection on all power and signal input/ output line provide protection from voltage surges and other transient events
Mini-package size of the CNMCSFP/M allows the unit to be installed in those locations where space is at a premium.
Supports Jumbo Frames up to 10K Bytes for streaming video applications
Bi-color LED status indicators confirm operating status
Hot-swappable rack modules

Need a different version? See all Bosch Parts Accessories

Chat Now for Qty Discount

Add to Quote

$1,408.14

Overview

Bosch Parts Accessory Model Overview

Products and parts from Bosch.

Bosch CNMCSFPPoE/M Products Overview

The ComNet CNMCSFP electrical-to-optical Ethernet media converters accept a 10/100 or 1000 Mbps electrical input and converts this to a 100 or 1000 Mbps optical output (selected by a dip switch) and the 100/1000 Mbps optical input back to the 10/100/1000 Mbps electrical output. "Auto-Negotiating" is supported on the copper interface side. These devices use either one or two optical fibers, depending upon the selection of sold-separately SFP optical module. A PoE model, the CNMCSFPPOE/M meets the IEE802.3at standard and provides 30 watts of PoE+ power. The series consists of a small-size single channel model, CNMCSFP/M; a ComFit standard size, single-channel model, CNMCSFP; a dual channel model, CNMC2SFP; and a quad channel model, the CNMC4SFP.

Detailed Specs

Interfaces/Ports

Total Number of Ports:

Network (RJ-45):

Yes

Number of PoE+ (RJ-45) Ports:

Media & Performance

Media Type Supported:

Twisted Pair
Optical Fiber

Fiber Mode Supported:

Single-mode
Multi-mode

Maximum Distance Supported:

74.56 Mile

I/O Expansions

Number of Total Expansion Slots:

Expansion Slot Type:

SFP (mini-GBIC)

Number of SFP Slots:

Network & Communication

Ethernet Technology:

Gigabit Ethernet

Network Technology:

10/100/1000Base-T
1000Base-X

Power Description

Power Source:

Power Supply

Physical Characteristics

Form Factor:

Standalone
DIN Rail Mountable

Height:

1.1"

Width:

3.3"

Depth:

2.5"

Miscellaneous

Package Contents:

CNMC[2,4]SFP[POE][/M] Transceiver/Media Converter
Power Supply

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Country of Origin:

United States

Warranty

Limited Warranty:

Lifetime

Item Numbers

GTIN: 0845770009903, 5711783231981

UPC: 845770009903

EAN: 0845770009903, 5711783231981

UNSPSC: 43201553
