Bosch - 4-Channel Digitally Encoded Video Transmitter + 4 Audio

4 channels of real-time 10-bit digitally encoded EIA/TIA RS-250C Short-Haul quality video on one optical fiber
4 channels of 24-bit/96 Khz sampling rate digitally encoded audio for the highest possible audio quality
Digitally Encoded Transmission: No video or audio performance degradation up to the maximum usable optical transmission distance or optical path loss
20Hz to 18Khz audio frequency response
Line-Level 600 ohm balanced audio input and audio output at a maximum level of +6dBm
Directly compatible with all NTSC, PAL, and SECAM CCTV camera systems
Wide optical dynamic range: optical attenuators are never required
Optical transmission distances of up to 48 km (30 miles)
Designed for installation in harsh out-of-plant/unconditioned industrial or roadside operating environments (-40º to +75ºC ambient). Fully compliant with the environmental requirements of NEMA TS-2 for Traffic Signal Control Equipment
Voltage transient protection on all power and signal input/ output line provide protection from voltage surges and other transient events

Need a different version? See all Bosch Parts Accessories

Chat Now for Qty Discount

Add to Quote

$3,477.29

Overview

Bosch Parts Accessory Model Overview

Products and parts from Bosch.

Bosch FVT40A4S Products Overview

The ComNet™ FVT/FVR40A4 series video/audio multiplexer utilizes 10-bit video encoding for true EIA/TIA RS-250C Short-Haul broadcast quality transmission, and 24-bit encoding at a 96 Khz sampling rate for the highest possible audio fidelity. Digitally encoded transmission ensures that the video and audio performance remain completely unaffected up to the maximum usable optical transmission distance or optical path loss. These environmentally hardened units provide the transmission of four independent simplex video and four independent simplex line-level audio channels over one multimode or single mode optical fiber. The FVT/FVR40A4 series is completely transparent to and universally compatible with any NTSC, PAL, or SECAM camera system. Plug-and-play design ensures ease of installation, and no electrical or optical adjustments are ever required.

Detailed Specs

Technical Information

Connectivity Technology:

Wired

Number of Input Devices Supported:

Maximum Operating Distance:

157480.31 ft

Media & Performance

Media Type Supported:

Optical Fiber

Power Description

Frequency:

50 Hz
60 Hz

Physical Characteristics

Transmitter Height:

2.20"

Transmitter Width:

5.30"

Transmitter Depth:

6.10"

Form Factor:

Rack-mountable

Miscellaneous

Package Contents:

4 Channel Video/Audio Transmitter (
9 Volt DC Plug-in Power Supply

Environmentally Friendly:

Yes

Environmental Certification:

WEEE
RoHS

Country of Origin:

United States

Warranty

Limited Warranty:

Lifetime

Item Numbers

GTIN: 0845770006643

UPC: 845770006643

EAN: 0845770006643

UNSPSC: 43222619
