Citizen CL-S703R Barcode Label Printer

The Citizen CL-S703R Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Citizen CL-S703 - Barcode Label Printers, Citizen CL-S703, With Rewinder

Print Resolution

300 dpi

Max Print Width

4.75 inch

A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
Enjoy the optimal performance in today's on-demand labeling applications
Produce high-quality documents with this monochrome printer to increase your productivity

Need a different version? See all Citizen CL-S703 Barcode Label Printers

Chat Now for Qty Discount

Add to Quote

Discontinued Need Assistance?

Overview

Full specifications (PDF)

Citizen CL-S703 Barcode Label Printer Model Overview

Part of the CL-S700 family of printers, the CL-S703 delivers an outstanding 300dpi resolution for pin-sharp printing. Tough, robust and built to withstand the rigorous of most industrial, warehouse and logistics environments, the CL-S703 is built to provide years of trouble-free use.

Citizen CL-S703R Barcode Label Printer Overview

The CL-S700 series is built with durability and ease of access in mind. Featuring a large, programmable front LCD control panel and a revolutionary Cross-Emulation™ control board that allows the printer to switch from Datamax to Zebra emulations at the touch of a button, the CL-S700 is designed for years of service. The CL-S700's front-loading rewinder option is unique in the industry. All rewinder loading and unloading is accomplished from the front of the unit. Ribbon and media loading is equally quick and easy with a Hi-Lift metal mechanism that opens to a full 90° allowing for easy access to theribbon and media path. 300 dpi version now available.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

10 in/s

Maximum Print Resolution:

300 dpi

Maximum Print Width:

4.10"

Barcode Symbology Supported:

Code 3 of 9
UPC-A
UPC-E
EAN/JAN-13
EAN/JAN-8
Interleaved 2 of 5
Code 128
HIBC
Codabar
Plessey
Case Code
UPC -2 Digits Add-on
UPC-5 Digits Add-on
Code 93
UCC/EAN 128
UPS Maxi Code
FIM
PDF-417
Data Matrix
QR Code
Aztec Code
RSS

Peel Facility:

Yes

Rewinder:

Yes

Application/Usage:

Desktop

Features:

LCD Display

Memory

Standard Memory:

16 MB

Flash Memory:

4 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Media Types & Handling

Media Type:

Label
Thermal Paper
Roll Paper

Media Sensor:

Adjustable Media Sensor

Media Thickness:

10 mil

Maximum Roll Diameter:

7.99"

Maximum Label Width:

4.65"

Maximum Label Length:

32"

Label Core Size:

2.99"

Power Description

Input Voltage:

110 V AC
220 V AC

Physical Characteristics

Height:

10.4"

Width:

10"

Depth:

19.3"

Miscellaneous

Package Contents:

CL-S703 Label Printer
Software CD

Platform Supported:

Environmentally Friendly:

Yes

Environmental Certification:

RoHS

Warranty

Limited Warranty:

2 Year

Item Numbers

UNSPSC: 43212108
