CP Technologies FCS-1150 Products

The CP Technologies FCS-1150 Products has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

CP Technologies - LevelOne H.264 3-Mega Pixel FCS-1150 PoE WDR IP Network Camera w/12x Optical Zoom (Day/Night), TAA Compliant - 3-MP, 12X Optical Zoom, PoE, WDR

For remote surveillance needs, this network camera is best suited
Up to 2048 x 1536 resolution for surveillance in real-time
CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
62.40 mm maximum focal length with sharp output to help identify and locate the object with added efficiency
f/3 maximum aperture for better light absorption and dependable, better-quality results
12x optical zoom for desired image clarity and maximum capturing convenience
Automatic focus mode for accurate, dedicated shots with maximum efficiency
Zoom lens type provides enhanced visual resolution and effectively maintains focus when its focal length changes
Wall Mount mount type ensures optimal results and maximum convenience
Day/Night feature for maximum productivity with added dependability

Need a different version? See all CP Technologies Parts Products

Chat Now for Qty Discount

Add to Quote

Discontinued Need Assistance?

Detailed Specs

Display & Graphics

Image Sensor Type:

CMOS

Image Sensor Size:

1/3"

White Balance Modes:

AWB

Color Supported:

Color
Monochrome

Field of View:

4.69° to 50.2°

Effective Camera Resolution:

3 Megapixel

Video

Video Formats:

MJPEG
H.264

Maximum Video Resolution:

2048 x 1536

Maximum Frame Rate:

30 fps

Lens

Lens Type:

Zoom

Minimum Focal Length:

5.20 mm

Maximum Focal Length:

62.40 mm

Lens Included:

Yes

Minimum Aperture:

f/1.8

Maximum Aperture:

f/3

Optical Zoom:

12x

Focus Modes:

Automatic

Exposure

Shortest Shutter Speed:

1/10000 Second

Longest Shutter Speed:

1/5 Second

Network & Communication

Connectivity Technology:

Wired

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

Protocols:

TCP
UDP
HTTP
HTTPS
DHCP
PPPoE
RTP
RTSP
IPv6
DNS
DDNS
NTP
ICMP
ARP
IGMP
SMTP
FTP
UPnP
SNMP
Bonjour

Interfaces/Ports

Network (RJ-45):

Yes

Audio Line In:

Yes

Audio Line Out:

Yes

Power Description

Maximum Power Consumption:

5.28 W

Physical Characteristics

Mount Type:

Wall Mount
Ceiling Mount

Height:

2.8"

Width:

3.2"

Depth:

6.9"

Weight (Approximate):

1.40 lb

Miscellaneous

Features:

Day/Night
SD Card Local Storage
2D Noise Reduction
Back Light Compensation (BLC)

Package Contents:

Zoom Network Camera, Day & Night, WDR
Mounting Kit
Screw Kit
Quick Installation Guide
Resource CD (User Manual, Utility, QIG)

System Requirements:

Operation Systems: Microsoft Windows 8/7/Vista/XP

Certifications & Standards:

CE
FCC
ONVIF

Country of Origin:

Taiwan

Item Numbers

GTIN: 0846359034224

UPC: 846359034224

EAN: 0846359034224

UNSPSC: 46171610
