CP Technologies FCS-3055 Products

The CP Technologies FCS-3055 Products has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
CP Technologies  -  LevelOne H.264 3-Mega Pixel Vandal-Proof FCS-3055 PoE WDR IP Dome Network Camera (Day/Night/Indoor/Outdoor), TAA Compliant - 3-MP, Vandal-Proof, PoE, WDR
  • Network camera - Helps achieve high-quality video results
  • Up to 2048 x 1536 resolution for surveillance in real-time
  • CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
  • 12 mm maximum focal length with sharp output to help identify and locate the object with added efficiency
  • f/1.4 maximum aperture for productive capturing according to focal length and lighting conditions
  • 4.3x optical zoom for bringing the subject closer for maximum surveillance efficiency
  • Manual focus mode for accurate, dedicated shots with maximum efficiency
  • Zoom lens type provides enhanced visual resolution and effectively maintains focus when its focal length changes
  • Wall mount is cost-effective, reusable, and long-lasting
  • Day/Night feature for better reliance and usability
Read More
Add to Quote
Display & Graphics
Image Sensor Type:
CMOS
Image Sensor Size:
1/3.2"
White Balance Modes:
AWB
Color Supported:
  • Color
  • Monochrome
Field of View:
28.2° to 70.5°
Effective Camera Resolution:
3 Megapixel
Video
Video Formats:
  • MJPEG
  • H.264
Maximum Video Resolution:
2048 x 1536
Maximum Frame Rate:
30 fps
Lens
Lens Type:
Zoom
Minimum Focal Length:
2.80 mm
Maximum Focal Length:
12 mm
Lens Included:
Yes
Maximum Aperture:
f/1.4
Optical Zoom:
4.3x
Focus Modes:
Manual
Exposure
Shortest Shutter Speed:
1/10000 Second
Longest Shutter Speed:
1/5 Second
Network & Communication
Connectivity Technology:
Wired
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Protocols:
  • TCP
  • UDP
  • HTTP
  • HTTPS
  • DHCP
  • PPPoE
  • RTP
  • RTSP
  • IPv6
  • DNS
  • DDNS
  • NTP
  • ICMP
  • ARP
  • IGMP
  • SMTP
  • FTP
  • UPnP
  • SNMP
  • Bonjour
Interfaces/Ports
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Power Description
Maximum Power Consumption:
6.49 W
Physical Characteristics
Mount Type:
  • Wall Mount
  • Ceiling Mount
Form Factor:
Dome
Durability:
  • Weather Proof
  • Vandal Proof
Height:
5.9"
Width:
5.9"
Depth:
4.6"
Weight (Approximate):
2.28 lb
Miscellaneous
Features:
  • Day/Night
  • SD Card Local Storage
  • Back Light Compensation (BLC)
  • 2D Noise Reduction
Indoor/Outdoor:
Outdoor
Package Contents:
  • FCS-3055 Network Camera
  • Screw Kit
  • Quick Installation Guide
  • Resource CD (User Manual, Utility,QIG)
  • Mounting Kit
System Requirements:
Operating Systems: Microsoft Windows 7/Vista/XP
Certifications & Standards:
  • IP67
  • IK10
  • CE
  • FCC
  • ONVIF
  • NEMA 4X
Impact Protection Rating:
IK10
Ingress Protection Rating:
IP67
Country of Origin:
Taiwan
Item Numbers
GTIN: 0846359034347
UPC: 846359034347
EAN: 0846359034347
UNSPSC: 46171610
