CP Technologies FCS-6020 Products

The CP Technologies FCS-6020 Products has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
CP Technologies  -  LevelOne H.264 2-Mega Pixel FCS-6020 PoE P/T IP Network Camera (Day/Night/Indoor) - 2-MP, PoE, P/T
  • Network camera - Helps achieve high-quality video results
  • Up to 1920 x 1080 video resolution
  • CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
  • 4 mm maximum focal length provides incredible detail and how effective is your network camera
  • f/2 maximum aperture for reliable, detailed, and sharp output with added dependability
  • Fixed lens type is ideal for indoor video surveillance where light levels are constant and unchanged
  • Ceiling Mount mount type ensures optimal results and maximum convenience
  • Day/Night feature for maximum efficiency and convenience
  • Wired connectivity technology delivers exceptional performance to offer maximum usability
Read More

Need a different version? See all CP Technologies Parts Products

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Discontinued Need Assistance?
CP Technologies FCS-6020 Products
CP Technologies FCS-6020 Products
CP Technologies FCS-6020 Products
CP Technologies FCS-6020 Products
CP Technologies FCS-6020 Products
CP Technologies FCS-6020 Products CP Technologies FCS-6020 Products CP Technologies FCS-6020 Products CP Technologies FCS-6020 Products CP Technologies FCS-6020 Products
Display & Graphics
Image Sensor Type:
CMOS
Image Sensor Size:
1/2.7"
White Balance Modes:
AWB
Color Supported:
  • Color
  • Monochrome
Field of View:
62°
Effective Camera Resolution:
2 Megapixel
Video
Video Formats:
  • MJPEG
  • MPEG-4
  • H.264
  • AVI
Maximum Video Resolution:
1920 x 1080
Maximum Frame Rate:
30 fps
Audio
Audio Formats:
AMR
Lens
Lens Type:
Fixed
Maximum Focal Length:
4 mm
Lens Included:
Yes
Lens Mount Type:
Board Mount
Maximum Aperture:
f/2
Exposure
Shortest Shutter Speed:
1/10000 Second
Longest Shutter Speed:
1/1 Second
Network & Communication
Connectivity Technology:
Wired
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Protocols:
  • TCP/IP
  • HTTP
  • SMTP
  • FTP
  • DDNS
  • UPnP
  • Telnet
  • NTP
  • PPPoE
  • DNS
  • DHCP
  • RTSP
  • Samba
Interfaces/Ports
USB:
Yes
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Power Description
Maximum Power Consumption:
8 W
Physical Characteristics
Mount Type:
Ceiling Mount
Height:
4.1"
Width:
4.1"
Depth:
4.3"
Weight (Approximate):
13.58 oz
Miscellaneous
Features:
  • Day/Night
  • Built-in Microphone
  • SD Card Local Storage
  • Motion Detection
Package Contents:
  • PT Network Camera, Day & Night, 2-Megapixel
  • Bracket
  • Power Adapter
  • RJ45 Ethernet Cable
  • Stand Kit
  • Quick Installation Guide
  • Resource CD (User Manual, Utility, 64-CH Monitoring Software)
System Requirements:
Operation Systems:
  • Microsoft Windows 7/Vista/XP
Browser:
  • Internet Explorer 6.x or above
  • Firefox
  • Chrome
  • Safari
Others Requirements:
  • Cell phone: 3GPP player
  • Real Player: 10.5 or above
  • Quick Time 6.5 or above
Certifications & Standards:
  • FCC
  • CE
Security Features:
  • Access Control: Multi-level user Access with Password Protection
  • IP Address Filtering
  • HTTPS Encrypted Data Transmission
Country of Origin:
Taiwan
Item Numbers
GTIN: 0846359034064
UPC: 846359034064
EAN: 0846359034064
UNSPSC: 46171610
