Custom America EVO-MR4 Credit Card Reader

The Custom America EVO-MR4 Credit Card Reader has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Custom America EVO-MR4 - Custom America EVO MR4 : Integrated 3-Track Msr for EVO-TP4/TM4 - Triple Track - 60 in/s - USB - Black

Need a different version? See all Custom America EVO-MR4 Credit Card Readers

Chat Now for Qty Discount

Add to Quote

Discontinued Need Assistance?

Custom America EVO-MR4 Credit Card Reader

Detailed Specs

Technical Information

Magnetic Stripe Track Configuration:

Triple Track

Magnetic Stripe Track Number:

Track 1
Track 2
Track 3

Minimum Swipe Speed:

3 in/s

Maximum Swipe Speed:

60 in/s

Number of Swipes (Head Life):

1000000

Magnetic Stripe Format:

AAMVA
ISO 7811

Bi-directional Reading:

Yes

Interfaces/Ports

USB:

Yes

Power Description

Input Voltage:

5 V DC

Physical Characteristics

Product Color:

Black

Height:

1.1"

Width:

1.3"

Depth:

3.5"

Weight (Approximate):

4.60 oz

Miscellaneous

Additional Information:

Swipe Function:

Swipe Speed: 3" - 60" (70mm - 1524mm) Per Second, Bi Directional
Indicator Buzzer: Programmable
Indicator Led: Tri-colored LED

Card Standard:

Reads ISO 7811, AAMVA, and other F2F formats

Media Thickness:

0.015" to 0.045" (0.38mm to 1.1mm)

Slot Width:

0.050" (1.3mm)

Advanced Features:

Data Editing: Extensive Advanced Data Editing Capabilities

Compatibility:

EVO-TM4
EVO-TP4

Warranty:

3-Year Warranty with 2-Day Advance Exchange Service

Certifications & Standards:

Environmentally Friendly:

Yes

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 0078283881937, 0736983815439, 0826635700142

UPC: 078283881937, 736983815439, 826635700142

EAN: 0078283881937, 0736983815439, 0826635700142

UNSPSC: 43211702
