GeoVision 801-SNVR-1611 Surveillance DVR

GeoVision - GeoVision GV-SNVR1611 Network Video Recorder - Network Video Recorder - HDMI

16-Channel video recording
Up to 4000 x 3000 resolution for each channel
Dual streams support
16-Port PoE+ (IEEE 802.3at) for camera connection
4K HDMI / 1080p VGA video output
2 SATA HDD drawer (3.5'') for up to 8 TB storage
Two-way audio
Four sensor inputs and one alarm output
Automatic search and set-up for IP cameras
Support for third-party IP cameras through ONVIF and RTSP protocol

Need a different version? See all GeoVision Parts Accessories

Chat Now for Qty Discount

Add to Quote

$633.75

GeoVision 801-SNVR-1611 Surveillance DVR

Overview

GeoVision Parts Accessory Model Overview

Products and parts from GeoVision.

GeoVision 801-SNVR-1611 Surveillance DVR Overview

The GV-SNVR1611 is an H.264/H.265 Linux-embedded Standalone Network Video Recorder which records video files directly to the internal hard drive, supporting up to 16 channels of IP cameras for network surveillance. GV-SNVR1611 has 16-port built-in PoE+ (IEEE 802.3at), functioning to carry network and power to IP cameras. Featuring with up to 4K resolution video output, GV-SNVR1611 eliminates the need of a separate PC to view and play back video from the unit. Its USB ports allow you to connect a USB flash drive to import or export system settings, update firmware, save snapshot files and back up video in AVI format.

Detailed Specs

Technical Information

Total Number of Channels:

Connectivity Technology:

Wired

System Components:

Network Video Recorder

Video

Video Formats:

AVI
H.264
H.265

Network & Communication

Ethernet:

Yes

Remote Management:

Yes

Interfaces/Ports

USB:

Yes

Total Number of Audio In Ports:

Total Number of Audio Out Ports:

Number of VGA Out:

HDMI:

Yes

Physical Characteristics

Height:

1.8"

Width:

12.4"

Depth:

15"

Weight (Approximate):

5.47 lb

Miscellaneous

Package Contents:

GV-SNVR1611 Network Video Recorder
AC Power Cord
2 x SATA Cable
2 x HDD Power Cable
8 x Screw (for HDD)
USB Mouse
Foam Foot
Download Guide
Warranty Card

Environmentally Friendly:

Yes

Warranty

Limited Warranty:

2 Year

Item Numbers

UNSPSC: 46171621
