Intermec 805-656-001 RFID Antenna

The Intermec 805-656-001 RFID Antenna has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Intermec IA33F  -  IA33F EXTERNAL EU/ETSI RFID ANTENNA, 868 MHZ, 8.5 DBIC, RIGHT HAND CIRCULAR POLARIZATION, N CONNECTOR
  • Provides gain of up to 8.5 dBi
  • Widely used in rfid
Read More

Need a different version? See all Intermec IA33F RFID Antennas

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Discontinued Need Assistance?
Intermec 805-656-001 RFID Antenna
Intermec 805-656-001 RFID Antenna
Intermec 805-656-001 RFID Antenna Intermec 805-656-001 RFID Antenna
Full specifications (PDF)
Intermec IA33F RFID Antenna Model Overview
The Intermec IA33F is a medium- to long-range antenna designed to support stationary RFID applications in indoor, ETSI-regulated environments. It is closely related to the IA33G, which serves FCC-regulated environments. The IA33F Panel Antenna is RoHS-compliant, with right-hand circular polarization.
Intermec 805-656-001 RFID Antenna Overview

The IA33F antenna is a right-hand circular polarized panel antenna appropriate for use in indoor, ETSI regulated environments. It can be used to support stationary RFID applications requiring medium to long read range.

Full specifications (PDF)
Technical Information
Frequency Band Type:
UHF
Operating Frequency Range:
865 MHz to 870 MHz
Antenna Gain:
8.5 dBi
Impedance:
50 Ohm
Polarization:
Right Hand Circular
Interfaces/Ports
Number of Connectors:
1
Connector Type:
Reverse N
Physical Characteristics
Height:
12.01"
Width:
12.01"
Depth:
0.98"
Weight (Approximate):
2.65 lb
Miscellaneous
Application/Usage:
RFID
Additional Information:
  • Sidelobe level: max. -16 dB
  • Axial ratio level: max. 2 dB
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Item Numbers
GTIN: 4054842363799
EAN: 4054842363799
UNSPSC: 43221706
