NEC PA311D-BK-SV Monitor

The NEC PA311D-BK-SV Monitor has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
NEC  -  31.1" COLOR CRITICAL DESKTOP DISPLAY WTH SPECRAVIEW ENGINE AND SPECRAVIEWII COLOR CALIBRATION, IPS, 4096X2160, 17:9, DISPLAYPORT 1.4, USB TYPE C, BLACK CABINET, 4 YEAR WARRANTY (SUGGESTED REPLACEMENT FOR PA302W-SV)
  • Is power-efficient with minimal heat production to ensure a prolonged, convenient usage
  • USB Type-C allows powerful and efficient transfer of data with maximum productivity
  • 31.1" viewable screen size provides a spectacular viewing experience
  • Allows pixels to adjust and accommodate moving scenes and video games with 8 ms response time
  • 350 Nit brightness gives an exceptional visible display for clear and consistent on-screen pictures
  • Over half a million pixels than UHD (3840x2160) and four times than Full HD makes you view even the finest details clearly to carry out intricate work for higher quality output
  • WLED backlight technology offers visual brilliance with maximum efficiency
  • 4096 x 2160 maximum resolution for a vivid, crystal clear display with added productivity
  • 75 Hz standard refresh rate reduces deterioration caused by blurring to ensure maximum productivity
  • Watch 4K movies with an aspect ratio of 17:9
Read More

Need a different version? See all NEC Parts Accessories

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Discontinued Need Assistance?
NEC PA311D-BK-SV Monitor
NEC PA311D-BK-SV Monitor
NEC PA311D-BK-SV Monitor
NEC PA311D-BK-SV Monitor
NEC PA311D-BK-SV Monitor
NEC PA311D-BK-SV Monitor NEC PA311D-BK-SV Monitor NEC PA311D-BK-SV Monitor NEC PA311D-BK-SV Monitor NEC PA311D-BK-SV Monitor
NEC Parts Accessory Model Overview
Products and parts from NEC.
NEC PA311D-BK-SV Monitor Overview

Reliable, calibrated color accuracy for the most demanding applications.The high resolution 31" MultiSync PA311D-BK-SV with the SpectraViewII color calibration solution is the premier desktop display for color critical applications including photography, advertising and video production. Utilizing a high performance IPS LCD panel and combined with the MDSVSENSOR3 calibrator, the MultiSync PA311D-BK-SV delivers high quality, perfect color. NEC's exclusive SpectraView Engine™ ensures that the colors that you see are always correct and stable, even between calibrations.

  • 100% coverage of AdobeRGB color space
  • Superior screen performance (1400:1 contrast ratio, 4096x2160 true 4K native resolution, 350cd/m2 brightness)
  • HDR support
  • 14-bit 3D internal programmable lookup tables (LUTs) for calibration
  • Picture in Picture and Picture by Picture modes increase productivity by displaying two sources simultaneously
  • MultiProfiler™ software provides complete control over the five picture modes, including the loading of any ICC profile directly into the monitor for optimal color space matching
  • DisplaySync ProTM controls three computers with only one keyboard and mouse
  • Wide connectivity includes both regular and Mini DisplayPort with 10-bit support, 10-bit HDMI, and USB Type-C with 65W of power delivery
  • Human Sensor saves power when not in use
  • DisplayPort cable compatibility notice
  • NaViSet Administrator 2: Free software solution that greatly eases administration and management of larger display device installations
Technical Information
Number of Screens:
1
Screen Size Class:
31"
Viewable Screen Size:
31.1"
Screen Mode:
4K
Panel Technology:
In-plane Switching (IPS) Technology
Response Time:
8 ms
Aspect Ratio:
17:9
Pixel Pitch:
6.7 mil
Backlight Technology:
WLED
Horizontal Frequency:
15 kHz to 135 kHz - Analog/Digital
Vertical Frequency:
24 Hz to 75 Hz
Video
Maximum Resolution:
4096 x 2160
Standard Refresh Rate:
75 Hz
Color Supported:
1.07 Billion Colors
Native Contrast Ratio:
1,400:1
Brightness:
350 Nit
Color Gamut:
  • 100% Adobe RGB
  • 97.4% NTSC
  • 99.9% sRGB
Audio
Number of Speakers:
2
Speakers:
Yes
Interfaces/Ports
HDMI:
Yes
USB:
Yes
DisplayPort:
Yes
USB Type-C:
Yes
Number of HDMI Inputs:
2
Number of USB Ports:
7
Number of DisplayPorts:
2
Total Number of USB Type-C Ports:
1
Power Description
Operating Power Consumption:
84 W
Standby Power Consumption:
500 mW
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
200 x 100
Height:
16.3"
Width:
29.1"
Depth:
3.1"
Height with Stand:
23"
Width with Stand:
29.10"
Depth with Stand:
11.90"
Weight (Approximate):
18.96 lb
Weight with Stand (Approximate):
32.85 lb
Miscellaneous
Package Contents:
  • PA311D-BK-SV Widescreen LCD Monitor
  • Power cord
  • DisplayPort cable
  • Mini DisplayPort to DisplayPort cable
  • USB 3.1 A to B cable
  • Mounting screws
  • SpectraViewII Color Calibration Kit (SVII-PRO-KIT)
  • Color calibration sensor (MDSVSENSOR3)
  • SpectraView software (SVIISOFT)
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
China
TAA Compliant:
No
Warranty
Limited Warranty:
4 Year
Item Numbers
GTIN: 0805736072068
UPC: 805736072068
EAN: 0805736072068
UNSPSC: 43211902
