Orion 17RTCSR CCTV Monitor

The Orion 17RTCSR CCTV Monitor has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Orion 17RTV LCD - 17RTC LCD CCTV Monitor (17 Inch, LED 5:41280 x 1024 1000 nits, 800 BNC In 2/Out 2, VGA in 1)

Sunlight Readable Ultra Bright LED with Transflective Technology
1280 x 1024 Resolution Sunlight Readable, 1500 Nits, 1000:1 Contrast
PIP / PBP Multi Display Function
3D Comb Filter, Deinterlace, Noise Reduction
BNC Video 2 In / 2 Out, S-Video 1 In / 1 Out, DVI-D 1 In, HDMI 2 In, VGA 1 In, Audio 2 In, PC Stereo 1 In
1W x 2 Built in Speaker
3 Years Part and Labor Warranty
Mount Options: Wall or Ceiling and Rack

Need a different version? See all Orion 17RTV LCD CCTV Monitors

Chat Now for Qty Discount

Add to Quote

Discontinued Need Assistance?

Overview

Full specifications (PDF)

Orion 17RTV LCD CCTV Monitor Model Overview

Orion's 17RTV LCD features a truly flat LCD screen delivering razor sharp images. Advanced image processing technologies like 3D comb filter and deinterlace function provides perfect image quality. The 17RTV LCD's design with DC 12V outlet and mounting hole enables it to be used as a public view monitor. Incorporated into it are versatile terminals like BNC and S-Video for security and industrial solutions. Its rigid case comes with heavy duty metal vessel and LCD protection glass. The accompanying unique stand allows for easy cable management, wall or rack mounting.

Orion 17RTCSR CCTV Monitor Overview

ORION Images 17 inch Sunlight readable 17RTCSR LED monitors offer enhanced ultra-high brightness LED color display for high ambient light applications. These Transflective enhanced anti-glare displays are readable under all lighting conditions including direct or indirect sunlight - the stronger the ambient light the brighter the image. The advantage of Transflective technology is that there is no extra heat generation lower power consumption, contrast and brightness is naturally brighter to help preserve the life of the back light. They are designed for use in applications such as industrial machinery, kiosk, ATM machines and and order confirmation system

Detailed Specs

Full specifications (PDF)

Technical Information

Number of Screens:

Screen Size Class:

17"

Viewable Screen Size:

17"

Screen Mode:

SXGA

Aspect Ratio:

5:4

Backlight Technology:

LED

Video

Maximum Resolution:

1280 x 1024

Color Supported:

16.7 Million Colors

Contrast Ratio:

1,000:1

Brightness:

1500 Nit

Audio

Speakers:

Yes

Interfaces/Ports

DVI:

Yes

HDMI:

Yes

VGA:

Yes

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

100 x 100

Color:

Black

Height:

13.2"

Width:

14.9"

Depth:

3.4"

Weight (Approximate):

13.01 lb

Miscellaneous

Country of Origin:

South Korea

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 0836228000467

UPC: 836228000467

EAN: 0836228000467

UNSPSC: 43211902

Reviews

Q&A

Get help from a Barcoding Expert!

The Orion 17RTCSR CCTV Monitor is also known as ORI-17RTCSR
