Bezel Width:
0.90"
Planar Parts Accessory Model Overview
Products and parts from Planar.
Planar 998-2259-00 Digital Signage Display Overview
Essentials for Digital Signage Applications
The Planar® PS Series 4K line of professional large format LCD displays offers a rich feature-set specifically designed for digital signage applications. From static content viewing to content interaction, Planar PS Series 4K displays have you covered for a variety of retail, corporate or museum applications.
Available in 50" , 55" and 65" , Planar PS Series 4K models feature narrow bezels, a slim profile and twice the brightness of typical consumer televisions, delivering a sleek look and beautiful image quality. For interactive content, touch models are also available. Each Planar PS Series 4K display is excellent for 24x7 operation and can be mounted in either landscape or portrait orientation. Planar PS Series 4K displays deliver vibrant ultra-high definition images and messages that captivate the attention of any audience.
Digital Signage Ready
Planar PS Series 4K displays power on with an embedded Android® operating system to support cloud-based digital signage applications. With embedded Wi-Fi, there's no need to physically connect the display to a network, adding the flexibility to install the display wherever needed.
Interactive Multi-Touch
Planar PS Series 4K displays with 20-point interactivity offer multi-touch infrared touch technology and a protective glass surface to help keep moisture, dust and dirt away from the display and maintaining its pristine look.
Logo-Free
Planar PS Series 4K displays are logo-free, keeping the spotlight on your brand, not ours. Unbranded bezels are perfect for installations in portrait or landscape configuration, and are only available from Leyard and Planar.
TAA Compliant
Organizations that prefer to use products that have been manufactured in the United States or countries designated in the United States' Trade Agreements Act (TAA) need look no further, as each model is TAA compliant.
More 4K LCD Displays
Need something larger? Multi-source viewing? ADA compliance? Explore Leyard's and Planar's other best-in-class 4K LCD solutions.
Technical Information
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Touchscreen:
Yes
Display Resolution:
3840 x 2160
Pixel Pitch:
12.4 mil
Backlight Technology:
Direct LED
Video
Scan Format:
2160p
Color Depth:
10-bit
Brightness:
500 Nit
Color Gamut:
72% NTSC
Network & Communication
Ethernet:
Yes
Wireless LAN:
Yes
Interfaces/Ports
USB:
Yes
HDMI:
Yes
Serial:
Yes
Number of DisplayPorts:
1
Software
Operating System:
Android 6.0 Marshmallow
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Physical Characteristics
Product Color:
Black
VESA Mount Standard:
400 x 400
Height:
28.9"
Width:
49.7"
Depth:
3.4"
Weight (Approximate):
65 lb
Miscellaneous
Package Contents:
- PS5574KT-N Interactive LCD Digital Signage Display
- US and EU power cords
- HDMI cable
- IR cable
- USB A to B cable
- Remote control
- WiFi antenna
- Cable clips
- QuickStart Guide
Certifications & Standards:
cTUVus
Environmentally Friendly:
Yes
Country of Origin:
Taiwan
TAA Compliant:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC:
43211902
Get help from a Barcoding Expert!
The Planar 998-2259-00 Digital Signage Display is also known as
998-2259-00
