Planar 998-2949-00 Digital Signage Display

Planar - Digital Signage Display, Planar, 32" Touch Anti-Glare Monitor, 2K, 10Pt Projected Capacitive QHD Wide Ips LCD, USB C, HDMI, Dp, USB Hub, Speakers, IP65, Black, No Desk Stand.

Experience an energetic display of colors, contrast and pictures with the wqhd lcd touchscreen monitor
Multi-touch activation can be performed with the Projective Capacitive touchscreen technology i.e. you can input from two fingers at a time.
Experience a new level of viewing pleasure with Wide Quad High Definition (WQHD) that features 4 times the resolution of standard HD
Edge LED backlighting technology enabled for a bright and sharp display
Enjoy crisp content and energetic hues with the 350 Nit brightness
HDMI interface allows connectivity to a variety of HD devices including gaming consoles, laptop PCs, Blu-ray players, digital cameras and many others for the ultimate high-definition display
VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs

Need a different version? See all Planar Parts Accessories

Chat Now for Qty Discount

Add to Quote

$1,168.80

In Stock

Planar 998-2949-00 Digital Signage Display

Overview

Planar Parts Accessory Model Overview

Products and parts from Planar.

Planar 998-2949-00 Digital Signage Display Overview

The Planar® PT3270Q is a 32" interactive IPS LCD monitor with a 10-point touch screen and Quad HD resolution ideal for mounted applications. The big, bright, 10-bit panel provides 1.07 billion colors. The all glass front surface is anti-glare coated, reducing reflection, and is dust and water tight. It features a VESA 200 x 200 pattern for convenient mounting. A single USB-C cable delivers video, audio, and touch connectivity. The PT3270Q is perfect for retail and kiosk applications, enterprise IT, control rooms, and industrial environments.

32" IPS LCD 10-pt touch with QHD (2560x1440) resolution
Water & dust protection IP65 (front) with anti-glare coating
USB Type-C, DisplayPort, HDMI inputs
Various touch modes: glove, waterproof, behind cover glass

Detailed Specs

Technical Information

Screen Size Class:

32"

Viewable Screen Size:

31.5"

Screen Mode:

WQHD

Panel Technology:

In-plane Switching (IPS) Technology

Response Time:

14 ms GTG

Aspect Ratio:

16:9

Horizontal Viewing Angle:

178°

Vertical Viewing Angle:

178°

Backlight Technology:

Edge LED

HDCP Supported:

Yes

Features:

Anti-glare
Water Proof
Anti-reflective

Vertical Frequency:

49 Hz to 76 Hz

Operation Hours:

16 Hours/ 7 Days

Ingress Protection (IP) Rating:

IP65

Video

Maximum Resolution:

2560 x 1440

Color Supported:

1.07 Billion Colors

Native Contrast Ratio:

1,000:1

Brightness:

350 Nit

Touchscreen Information

Touchscreen Type:

Projected Capacitive

Multi-touch Screen:

Yes

Number of Simultaneous Touchpoints:

Interfaces/Ports

HDMI:

Yes

USB:

Yes

DisplayPort:

Yes

USB Type-C:

Yes

Power Description

Operating Power Consumption:

26 W

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

200 x 200

Height:

16.9"

Width:

28.9"

Depth:

2.4"

Weight (Approximate):

28 lb

Miscellaneous

Package Contents:

PT3270Q 32" Touch Screen Monitor
Power Cord
USB Cable (C to C)
HDMI Cable
DP Cable
USB Cable (A to C)
User's Guide

Environmentally Friendly:

Yes

Environmental Certification:

RoHS

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 0810689009979

UPC: 810689009979

EAN: 0810689009979

UNSPSC: 43211903

Reviews

Q&A

Get help from a Barcoding Expert!

The Planar 998-2949-00 Digital Signage Display is also known as 998-2949-00
