PowerDsine PD-9001GR/AT/AC-US Accessory

The PowerDsine PD-9001GR/AT/AC-US Accessory has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

PowerDsine - 1-Port High Power Midspan, 30W per Port, IEEE802.3AT 10/100/1000 BaseT, AC Input

Need a different version? See all PowerDsine Parts Accessories

Chat Now for Qty Discount

Add to Quote

Discontinued Need Assistance?

Overview

PowerDsine Parts Accessory Model Overview

Products and parts from PowerDsine.

PowerDsine PD-9001GR/AT/AC-US Accessory Overview

Microsemi's PD-9001GR is a single port, high-power solution for remote powering of current and emerging high power applications. Generating up to 30W, the PD-9001GR enables remote power for a new range of applications including 802.11ac Access Points, pan-tiltzoom (PTZ) cameras and video-phones. It complies with the IEEE 802.3at PoE+ standard and is backward compatible with IEEE802.3af. It can power both existing 10/100Base-T network devices and emerging wireless 1000Base-T devices such as wireless IEEE 802.11ac access points and IP Cameras.

Features

Single-port Gigabit PoE Midspan, 802.3at Compliant with 2-event classification
Backwards compatible with IEEE802.3af
30W output power from -20ºC to +40ºC, 25W output at +55ºC
1000Base-T compatible
Safe & reliable power over existing Ethernet infrastructure, only PoE devices receive power
Automatic detection and protection of non-standard devices
Plug-and-play installation
Guaranteed up-time

Detailed Specs

Power Description

Input Voltage:

120 V AC
230 V AC

Maximum Output Voltage:

55 V DC

Maximum Input Current:

800 mA

Minimum Frequency:

50 Hz

Maximum Frequency:

60 Hz

Maximum Output Power:

30 W

Interfaces/Ports

Input Ports:

1 x 10/100/1000Base-T

Output Ports:

1 x 10/100/1000Base-T

Physical Characteristics

Height:

1.3"

Width:

2.2"

Length:

5.5"

Weight (Approximate):

7.04 oz

Miscellaneous

Compatibility:

Access Points
Pan-Tiltzoom (PTZ) Cameras
Video-Phones
Network Devices

Certifications & Standards:

CE
FCC Part 15, Class B
EN 55022 Class B (Emissions)
EN 55024 (Immunity)
VCCI
UL/cUL Per IEC 60950-1
IEEE802.3af
IEEE802.3at

Environmentally Friendly:

Yes

Country of Origin:

China

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0818245045201

UPC: 818245045201

EAN: 0818245045201

UNSPSC: 39121004

Reviews

Q&A

Get help from a Barcoding Expert!

The PowerDsine PD-9001GR/AT/AC-US Accessory is also known as PDS-PD9001GRATACUS
