Powerware 5SC500 Power Device

Powerware - EATON 5SC 500VA TOWER (120V)

Enables you to customize UPS settings, view load and power consumption through the graphical interactive LCD screen interface
Integrates with Intelligent Power Manager (IPM) for point-to-point power management (USB/serial) or network-based using server as a proxy. View Demo
Offers user-replaceable batteries
Extends battery service life by 50% with ABM technology
Protects you with a three-year warranty, which includes the battery
Corrects a wide range of input voltage variations through buck and boost operation
Provides high quality pure-sinewave output capability, protecting any sensitive equipment connected ensuring consistent input voltage to the loads protected

Need a different version? See all Powerware Parts Accessories

Chat Now for Qty Discount

Add to Quote

$284.12

Overview

Powerware Parts Accessory Model Overview

Products and parts from Powerware.

Powerware 5SC500 Power Device Overview

The flexible Eaton 5SC UPS delivers affordable and reliable protection for small business servers, storage and network equipment. The LCD interface provides clear status of UPS key parameters and allows configuration for output voltage, audible alarm and power input sensitivity. By using Eaton's Intelligent Power Manager software with the 5SC UPS you get up-to-the-minute information on the status of power in your network. The 5SC offers pure sinewave output for sensitive equipment as well as buck and boost operation to correct a wide range of input voltage variations without using batteries.

Detailed Specs

Technical Information

Plug/Connector Type:

NEMA 5-15P

Receptacle Type:

NEMA 5-15R

Receptacle Detail:

4 x NEMA 5-15R

Protection Type:

Surge

Cord Length:

5.91 ft

Power Description

Load Capacity:

500 VA/350 W

Input Voltage:

120 V AC

Output Voltage:

120 V AC

Management

Battery Management:

ABM Technology

Interfaces/Ports

Serial Port:

Yes

Network (RJ-45):

Yes

USB:

Yes

Battery Information

Battery Characteristics:

Maintenance-free, Sealed

Battery Chemistry:

Lead Acid

Hot Swappable:

Environmental Conditions

Maximum Operating Temperature:

95°F (35°C)

Sound Emission:

55 dB

Physical Characteristics

Product Color:

Black

Height:

8.2"

Width:

5.9"

Depth:

9.4"

Form Factor:

Tower

Weight (Approximate):

15.21 lb

Miscellaneous

Package Contents:

5SC UPS
User Manual CD
Intelligent Power Manager Software CD
USB Cable
Serial Cable (RJ45 to DB9)
Safety Instructions
Limited Warranty Details

Certifications & Standards:

CE
cULus
NOM
IEC 62040-2:2006 Cat C2
CISPR22 Class A
FCC part 15 Class A

Software Included:

Eaton Intelligent Power Software

Environmentally Friendly:

Yes

Environmental Certification:

RoHS

Country of Origin:

Philippines

Warranty

Limited Warranty:

2 Year

Item Numbers

GTIN: 0014444658116, 0160932109735, 0743172045089, 0783555242919

UPC: 014444658116, 160932109735, 743172045089, 783555242919

EAN: 0014444658116, 0160932109735, 0743172045089, 0783555242919

UNSPSC: 39121011
