Powerware PW12S15K-PD Products

Powerware - PW9170+ PRE-CONFIG SYSTEM 9kVA EXPANDABLE TO 18kVA N+X

Need a different version? See all Powerware Parts Accessories

Chat Now for Qty Discount

Add to Quote

$17,438.03

Overview

Powerware Parts Accessory Model Overview

Products and parts from Powerware.

Powerware PW12S15K-PD Products Overview

With a scaleable, modular and redundant design, the Powerware 9170+ Rackmount UPS provides advanced backup power and power quality management and offers the highest level of power protection and power quality of any Rackmount UPS power supply in the 3-18 kVA range.

Detailed Specs

Technical Information

Plug/Connector Type:

Hardwired

Receptacle Type:

NEMA L14-30R
NEMA L6-30R
NEMA 5-20R

Receptacle Detail:

3 x NEMA L14-30R
3 x NEMA L6-30R
12 x NEMA 5-20R

Power Description

Load Capacity:

15 kVA

Input Voltage:

110 V AC
220 V AC

Output Voltage:

120 V AC
208 V AC
240 V AC

Input Frequency:

60 Hz

Output Frequency:

60 Hz

Waveform Type:

Sine Wave

Management

Alarm:

Low Battery
High Battery
Low AC Output
High AC Output
High AC Input
Output Overload
Overload Shutdown
High Heatsink Temperature
Emergency Power Off
Module Failure
Excessive Transfer
Precharge Failure
Incompatible Module
Fan Failure
Low Runtime
Check Memory
Check Battery Open Cell
Check Battery Weak Battery
Low Redundancy Insufficient Battery
Low Redundancy Insufficient Module
Check Battery
Phase Error

Bypass Switch:

Automatic

Emergency Power OFF:

Yes

Controls/Indicators

Status Indicators:

Battery Test Failed

Interfaces/Ports

Modular Slots:

2 x Communications Slot

Battery Information

Battery Characteristics:

Maintenance-free

Battery Chemistry:

Lead Acid

Backup/Run Time (Full Load):

8 Minute

Backup/Run Time (Half Load):

24 Minute

Typical Battery Recharge Time:

4 Hour

Environmental Conditions

Maximum Operating Temperature:

104°F (40°C)

Sound Emission (A-Weighted):

50 dB(A)

Miscellaneous

Additional Information:

Eliminates single point-of-failure with N+X power and logic redundancy
Grows with changing IT environments by incorporating scalable design of 3 kVA power modules and batteries

Certifications & Standards:

UL
CUL
FCC class A
IEEE/ANSI C62.41

Warranty

Limited Warranty:

2 Year

Item Numbers

GTIN: 0783555055632

UPC: 783555055632

EAN: 0783555055632

UNSPSC: 39121011
