Powerware PW6S6K UPS

Powerware UPS  -  6 kVA Expandable 9 kVA N+X Hardwired, 33.3 x 17.0 x 25.5

Need a different version? See all Powerware UPS Accessories

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
$8,140.05
Powerware PW6S6K UPS
Powerware PW6S6K UPS
Powerware PW6S6K UPS Powerware PW6S6K UPS
Powerware UPS Accessory Model Overview
Powerware UPS and Power Supplies.
Powerware PW6S6K UPS Overview

With a scaleable, modular and redundant design, the Powerware 9170+ Rackmount UPS provides advanced backup power and power quality management and offers the highest level of power protection and power quality of any Rackmount UPS power supply in the 3-18 kVA range.

Technical Information
Plug/Connector Type:
Hardwired
Receptacle Type:
  • NEMA L14-30R
  • NEMA L6-30R
  • NEMA 5-20R
Receptacle Detail:
  • 2 x NEMA L14-30R
  • 2 x NEMA L6-30R
  • 12 x NEMA 5-20R
Power Description
Load Capacity:
9000 VA
Input Voltage:
220 V AC
Output Voltage:
  • 240 V AC
  • 200 V AC
  • 220 V AC
Input Frequency:
60 Hz
Output Frequency:
60 Hz
Management
Network Management:
SNMP Manageable
Bypass Switch:
Automatic
Emergency Power OFF:
Yes
Interfaces/Ports
Modular Slots:
2 x Communications Slot
Battery Information
Battery Characteristics:
Maintenance-free
Battery Chemistry:
Lead Acid
Backup/Run Time (Full Load):
8 Minute
Backup/Run Time (Half Load):
24 Minute
Typical Battery Recharge Time:
4 Hour
Environmental Conditions
Maximum Operating Temperature:
104°F (40°C)
Sound Emission (A-Weighted):
50 dB(A)
Physical Characteristics
Form Factor:
Tower
Height:
33.3"
Width:
17"
Depth:
26"
Weight (Approximate):
269 lb
Miscellaneous
Package Contents:
  • Powerware PW9170+ 6kVA to 9 kVA Tower UPS
  • 1 x 6 slot enclosure
  • 2 x Power module
  • 4 x Battery module
  • 1 x Caster kit
Additional Information:
  • Eliminates single point-of-failure with N+X power and logic redundancy
  • Grows with changing IT environments by incorporating scalable design of 3 kVA power modules and batteries
Certifications & Standards:
  • UL
  • CUL
  • FCC class A
  • IEEE/ANSI C62.41
Country of Origin:
United States
Warranty
Limited Warranty:
2 Year
Item Numbers
UNSPSC: 39121011
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Powerware PW6S6K UPS is also known as POW-PW6S6K
