Powerware T800F-25000 Accessory

Powerware UPS  -  PWRSURE 800 FLR/HW 25 kVA
Add to Quote
$19,811.09
Powerware UPS Accessory Model Overview
Powerware UPS and Power Supplies.
Powerware T800F-25000 Accessory Overview

Every facet of our daily life is being automated by faster microprocessors and microprocessor-based equipment which require steady continuous power. As market pressures force the deregulation of the electrical industry, utility companies have less and less control over the quality of power supplied to sensitive electronic equipment. In industry, the effects of unreliable power can be seen in the erroneous motion of computer-controlled milling machines, causing irreparable damage to expensive manufacturing equipment or finished products. Additionally, poor power quality can cause motor driven equipment to operate inefficiently and overheat, causing premature failure. In data processing and medical applications, the effects of unreliable power can be translated into incorrect data, lost memory, premature component failure, mixed and garbled data and inaccurate diagnostics. Power conditioning alleviates these problems.

Technical Information
Protection Type:
  • Lightning
  • AC Surge
  • Harmonics
  • AC Noise
Plug/Connector Type:
Hardwired
Receptacle Type:
Hardwired
Power Description
Load Capacity (VA):
25 kW
Load Capacity (Watt):
25 kW
Input Voltage:
  • 208 V AC
  • 240 V AC
  • 480 V AC
Output Voltage:
240 V AC
Maximum Frequency:
50 Hz
Physical Characteristics
Height:
39.5"
Width:
35"
Depth:
25"
Weight (Approximate):
1070 lb
Miscellaneous
Additional Information:
  • Line Regulation: +/- 2% Vout for +10% to -20% Vin at 100% Load
  • Load Regulation: +/-3% for 0% to 100% load
  • Immunity to Distortion: @40% THD Vin, 5% Max THD Vout
  • Ride-through Capability: 1 cycle
  • Voltage Recovery: 2 cycles to 95%, 3 cycles to 100%
  • K-Factor: K-30 Rated
  • Power Factor Correction: Input of 0.95 typical
  • Harmonic Attenuation: -23dB for load reflected harmonics
  • Galvanic Isolation: NEC 250-5d, 0.001 pf
  • Surge Protection: UL 1449 Rating 330v; ANSI/IEEE C62.41-Cat B3
  • Common Mode Noise Attenuation: 140 dB
  • Transverse Mode Noise Attenuation: 120 dB
  • Reliability: 200,000 hours (MTBF)
  • Audible Noise: 1 meter A scale, 52dB to 56dB
  • Efficiency: Approx. 92% at full load
Country of Origin:
United States
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0743172021267
UPC: 743172021267
EAN: 0743172021267
UNSPSC: 39121020
