Printronix 199406-001 Barcode Label Printer

The Printronix 199406-001 Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Printronix T5204 - Printronix ThermaLine T5204r Network Label Printer - Monochrome - 10 in/s Mono - 203 dpi - Serial, Parallel, USB

Printer Type

Industrial

Printing Technology

Thermal Transfer

Interface Options

Parallel, Serial (RS-232), USB

Print Resolution

203 dpi

Max Print Width

4.5 inch

Direct Thermal/Thermal Transfer Printer offers reliable performance with outstanding printing quality
Delivers high-speed, hassle-free labeling solution for your business needs
Produce high-quality documents with this monochrome printer to increase your productivity

Need a different version? See all Printronix T5204 Barcode Label Printers

Chat Now for Qty Discount

Add to Quote

Discontinued Need Assistance?

Printronix 199406-001 Barcode Label Printer

Overview

Full specifications (PDF)

Printronix T5204 Barcode Label Printer Model Overview

The T5204 delivers dependable and reliable 4" wide barcode printing at 203 dpi for compliance labeling and accommodates higher density barcodes, increased graphics or smaller text with snap-in print heads. When used in conjunction with ODV technology (Online Data Validation), the T5204 provides verification of scannable barcodes at the point of label creation. Designed as RFID Smart Ready, the T5204 converts to an UHF RFID printer encoder as RFID requirements enter the supply chain. Combining barcode compliance and RFID technology the T5204 links barcode and EPC data together for storage, retrieval, electronic audits and data synchronization.

Printronix 199406-001 Barcode Label Printer Overview

Based on the 5r Multi-Technology Platform, the ThermaLine T5204r is an industrial thermal bar code printer designed to operate in challenging environments. Through leadership by design, the T5204r combines reliability, utility, power and flexibility for demanding environments and provides the open migration to RFID for future requirements. T5204r supports the widest range of connectivity and control without sacrificing performance and provides the ability to meet new application and compliance requirements. The T5204r delivers dependable and reliable bar code printing for compliance labeling and accommodates higher density bar codes, increased graphics or smaller text with snap-in print heads.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

10 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

4.10"

Barcode Symbology Supported:

Australia Post
Aztec Code
BC35
BC412
Codabar
Code 11
Code 35
Code 39
Code 93
Code 128-A
Code 128-B
Code 128-C
Data Matrix
EAN-8
EAN-13
FIM
125 German
Interleaved 2 of 5
ITF-14
Matrix
Maxi Code
MSI
PDF-417
Planet Code
Plessey
POSTNET
PostBar
ROYALBAR
RSS-14
Telepen
UCC/EAN 128
UPC-A
UPC-E
UPC-E0
UPCSHIP
UPS11

Rewinder:

Yes

Memory

Standard Memory:

32 MB

Memory Technology:

DRAM

Flash Memory:

8 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Media Types & Handling

Media Type:

Roll Paper
Fanfold
Ticket
Film
Synthetic Media
Direct Thermal Paper
Thermal Transfer Label

Media Size:

4.50" x Roll Paper
1" x Roll Paper

Maximum Roll Diameter:

Power Description

Input Voltage:

110 V AC
220 V AC

Miscellaneous

Additional Information:

Sensing Methods:

Reflective
Transmissive

Platform Supported:

Warranty

Limited Warranty:

1 Year

Item Numbers

UNSPSC: 43212108
