Socket Mobile CX4040-3103 Barcode Scanner

Socket Mobile - Barcode Scanners, Socket-Mobile, Socketscan S820 Black, 50 Bulk (No Acc Incl)

Compatible - with Apple® iOS devices (iPad®, iPhone®, iPod Touch®) and Android, Windows®, Mac and Linux.
Certified by Apple® for iOS devices - Guaranteed Compatibility - With Capture SDK integrated in over 700+ applications, Socket Mobile readers are one of the most natively integrated readers available today
? Bluetooth Wireless Technology - Connects easily to a wide range of Bluetooth enabled smartphones, tablets,notebooks and desktop computers.
Scanning - Fast 2D & 1D, omni-directional, barcode scanning with highly visible and safe aimer.
Decoding Ability - Reads damaged and poorly printed barcodes.
Size & Weight - Measuring less than ½ inch (1.27cm) thick and weighing less than two ounces (48g)
User Feedback - With audible tones, vibration and Bluetooth connection indicators.
Long-Lasting, Replaceable, Rechargeable Battery - Power to last a full work day
One-Handed Operation - Attachable clip included.
1-Year Warranty - optional extended warranty available

Need a different version? See all Socket Mobile Parts Accessories

Chat Now for Qty Discount

3-year Premium Plus ($49.50)

No, stay at premium support package

Add to Quote

$15,651.43

Socket Mobile CX4040-3103 Barcode Scanner

Overview

Socket Mobile Parts Accessory Model Overview

Products and parts from Socket-Mobile.

Socket Mobile CX4040-3103 Barcode Scanner Overview

Linear Barcode Plus QR Code Scanner

The Socket Mobile S820 is a 1D/2D linear barcode & QR Code barcode reader with Bluetooth wireless technology. Small, thin and easy to use, the reader is optimized for attaching to mobile devices, enabling one-handed operation. The S820 can scan barcodes printed on labels or displayed on device screens. It reads the most popular 2D/1D barcodes and is perfect for retail point of sale, inventory management, sales order entry, field service, and other mobile business applications.

Approximately the same size as a credit card, measuring less than ½ inch (1.27cm) thick and weighing less than two ounces, the S820 is one of the smallest and lightest high quality barcode reader available in the market today. The S820 slips neatly into your pocket and fits comfortably in the palm of your hand when attached to a smartphone. It is compatible with all applications used with other Socket Mobile readers with "NO" software update required.

Detailed Specs

Technical Information

Connectivity Technology:

Wireless

Scanning Capability:

Barcode Symbology Supported:

1D:

Codabar
Code 39
Code 93
Code 128
EAN-13
EAN-8
Interleaved 2 of 5
ISBT 128
UPC A
UPC E1
Chinese 2 of 5
Codabar
Code 11
Code 16KCode 39
Code 93
Code 128
Discrete 2 of 5
EAN-13
EAN-8
GS1 Databar
Industrial 2 of 5
Interleaved 2 of 5
Matrix 2 of 5
MSI Plessey
UPC A
UPC E1
Standard 2 of 5
UK Plessey

2D:

Data Matrix
Micro QR Code
PDF417
QR Code
Aztec
Data Matrix
Han Xin
Micro PDF417
Micro QR Code
PDF417
QR Code

Light Source:

LED

Image Sensor Type:

Linear

Scan Pattern:

Omni-directional

Scanning Distance:

14.96"

Cable Type Included:

USB

Field of View (Horizontal):

45°

Field of View (Vertical):

34°

Maximum Ambient Light:

100000 lux

Drop Specification:

Multiple drops to vinyl covered concrete at about 3 ft or 1 m

Minimum Print Contrast:

25%

Maximum Element Resolution (Code 39):

5 mil

Maximum Element Resolution (DataMatrix):

10 mil

Network & Communication

Bluetooth:

Yes

Battery Information

Battery Included:

Yes

Battery Weight:

0.44 oz

Physical Characteristics

Form Factor:

Handheld

Product Color:

Black

Weight (Approximate):

1.69 oz

Miscellaneous

Package Contents:

S820 barcode scanner
Micro USB Charging Cable
Rechargeable battery (pre-installed)
Universal Klip
Get Started Insert
Klip & FlexGuard for 800 Series
Wrist Strap

Ingress Protection (IP) Rating:

IP40

Application/Usage:

Retail
Hospitality
Logistics
Healthcare
Inventory
Transportation
Warehouse
Field Sales/Service

Platform Supported:

iOS
Android
PC
Mac

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0758497122155

UPC: 758497122155

EAN: 0758497122155

UNSPSC: 43211701
