Socket Mobile CX4046-3109 Barcode Scanner

Socket Mobile - Barcode Scanners, Socket-Mobile, Durascan D820, (Charger Sold Separately)

"Compatible - with Apple® iOS devices (iPad®, iPhone®, iPod Touch®) and Android, Windows®, Mac and Linux.
"Certified by Apple® for iOS devices - Guaranteed Compatibility - With Capture SDK integrated in over 700+ applications, Socket Mobile scanners are one of the most natively integrated scanners available today.
Bluetooth Wireless Technology - Connects easily to a wide range of Bluetooth enabled smartphones, tablets, notebooks and desktop computers.
Scanning - 2D & 1D omni-directional barcode scanning with visible and safe aimer.
Decoding Ability - Reads damaged and poorly printed barcodes.
Size & Weight - Measuring a little over ½ inch (16.76mm) thick and weighing 2.52 ounces (71.5g).
User Feedback - With audible tones, hand pulsation and Bluetooth indicator.
Long-Lasting Replaceable Battery - Power to last a full workday.
"One-Handed Operation - Attachable Klip included.
"Durable Casing - Rubber material for increased protection from drops.

Need a different version? See all Socket Mobile Parts Accessories

Chat Now for Qty Discount

3-year Premium Plus ($49.50)

No, stay at premium support package

Add to Quote

$395.86

Socket Mobile CX4046-3109 Barcode Scanner

Overview

Socket Mobile Parts Accessory Model Overview

Products and parts from Socket-Mobile.

Socket Mobile CX4046-3109 Barcode Scanner Overview

Linear Barcode Plus QR Code Scanner

The DuraScan D820 is a linear barcode & QR Code 1D/2D barcode reader with Bluetooth wireless technology. It reads the most popular 2D/1D barcodes and is perfect for retail point of sale, inventory management, sales order entry, field service, and other mobile business applications. Users can scan barcodes printed on labels or displayed on screens. Designed for mobility, durability and lasting up to two shifts. The external rubberized material increases drop protection. Easy to use and attachable to a mobile device, enabling one-handed operation, it slips neatly into your pocket and fits comfortably in the palm of your hand.

Detailed Specs

Technical Information

Connectivity Technology:

Wireless

Scanning Capability:

Barcode Symbology Supported:

1D:

Codabar
Code 39
Code 93
Code 128
EAN-13
EAN-8
Interleaved 2 of 5
ISBT 128
UPC A
UPC E1
Chinese 2 of 5
Codabar
Code 11
Code 16KCode 39
Code 93
Code 128
Discrete 2 of 5
EAN-13
EAN-8
GS1 Databar
Industrial 2 of 5
Interleaved 2 of 5
Matrix 2 of 5
MSI Plessey
UPC A
UPC E1
Standard 2 of 5
UK Plessey

2D:

Data Matrix
Micro QR Code
PDF417
QR Code
Aztec
Data Matrix
Han Xin
Micro PDF417
Micro QR Code
PDF417
QR Code

Light Source:

LED

Image Sensor Type:

Linear

Scan Pattern:

Omni-directional
Linear

Scanning Distance:

15"

Field of View (Horizontal):

45°

Field of View (Vertical):

34°

Maximum Ambient Light:

100000 lux

Drop Specification:

Multiple 6.5 ft. (2 m) drops to concrete

Minimum Print Contrast:

25%

Maximum Element Resolution (Code 39):

5 mil

Maximum Element Resolution (DataMatrix):

10 mil

Image Sensor Resolution:

1280 x 960

Network & Communication

Bluetooth:

Yes

Battery Information

Battery Included:

Yes

Battery Chemistry:

Lithium Polymer (Li-Polymer)

Battery Capacity:

700 mAh

Battery Weight:

0.44 oz

Maximum Battery Recharge Time:

8 Hour

Environmental Conditions

Operating Temperature:

32°F (0°C) to 122°F (50°C)

Storage Temperature:

-22°F (-30°C) to 158°F (70°C)

Humidity (Non-condensing):

5% to 95%

Physical Characteristics

Weight (Approximate):

2.52 oz

Miscellaneous

Package Contents:

D820 barcode scanner
Klip
Wrist Strap
1 year limited Warranty on DuraSled barcode scanner

Ingress Protection (IP) Rating:

IP40

Application/Usage:

Retail
Hospitality
Logistics
Healthcare
Inventory
Transportation
Warehouse
Field Sales/Service
Commercial Service

Platform Supported:

Mac
PC
Android

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
WEEE

Country of Origin:

United States

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0758497122179

UPC: 758497122179

EAN: 0758497122179

UNSPSC: 43211701
