StarTech MSTDP124DP Accessory

StarTech  -  Adapter, StarTech, 4-Port Displayport Multi-Monitor Adapter, Drives 4 x 1080P 60Hz Displayport Displays, Displayport 1.2/HBR2/MST (Multi Stream Transport), Built-In Displayport Cable
  • MULTI MONITOR ADAPTER FOR WINDOWS: 4-port DisplayPort MST hub drives up to four DP displays in extended or duplicate mode using a DP port on Windows desktop PCs or laptops | Not compatible with macOS
  • DISPLAY RESOLUTION: Quad monitor DisplayPort MST hub supports HD resolutions up to 1080p 60Hz on all four monitors
  • COMPATIBILITY: 4-Port DisplayPort MST video splitter works with laptops, computers or desktop graphics cards |Requires host system with DP 1.2/HBR2/MST or later from HP, Dell & Lenovo and AMD, Nvidia & Intel video cards
  • INCREASE PRODUCTIVITY: Increase productivity by extending your desktop at your workstation in the office/home office | MST technology uses your GPU/video card performance to deliver uncompressed video and use minimal system resources
  • EASY TO USE: Quad monitor adapter natively supports 4x DP monitors; Works w/Windows only and provides an easy driverless setup | Latching DisplayPort connector ensures a reliable connection and prevents accidental disconnection
  • CONVENIENCE: MST (multi-stream transport) hub is equipped with a built-in 7.5" (19cm) cable for video (DisplayPort) and an AC power adapter | Supports LPCM digital audio
  • GPU CAPABILITIES: Please check your system's GPU capabilities to determine max number of displays supported; Some GPU chips (such as Intel HD Graphics) are not capable of supporting four displays
Read More
Add to Quote
$127.15
In Stock
Video
Maximum Video Resolution:
3840 × 2160
Interfaces/Ports
DisplayPort:
Yes
Number of DisplayPort Inputs:
1
Number of DisplayPort Outputs:
4
Media & Performance
Maximum Operating Distance:
78.74"
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Physical Characteristics
Product Color:
Black
Product Material:
Plastic
Height:
0.6"
Width:
2.6"
Length:
15.2"
Weight (Approximate):
4.55 oz
Miscellaneous
Package Contents:
  • MST hub - DisplayPort to 4x DisplayPort
  • 1 x Universal Power Adapter (NA/EU/UK/AUS)
  • 1 x Quick Install Guide
Additional Information:
Hardware
  • Audio Yes
  • Chipset ID STDP4320
  • Converter Type MST Hub
  • Output Signal DisplayPort
  • Ports 4
Performance
  • Maximum Digital Resolutions 3840 x 2160 @30hz
  • Supported Resolutions 1024x768
  • 1280x720 (High-definition 720p)
  • 1920x1080 (High-definition 1080p)
  • 1920x1200
  • 2560x1440
  • 2560x1600
  • 3840 x 2160 (Ultra HD 4K) @30hz
  • Wide Screen Supported Yes
Environmental
  • Operating Temperature 0°C to 45°C (32°F to 113°F)
  • Storage Temperature -20°C to 70°C (-4°F to 158°F)
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • WEEE
  • REACH
Country of Origin:
China
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0065030860581, 0818242996315, 0996591022999
UPC: 065030860581, 818242996315, 996591022999
EAN: 0065030860581, 0818242996315, 0996591022999
UNSPSC: 32101529
