TRENDnet Parts Accessory Model Overview
Products and parts from TRENDnet.
- DEVICE INTERFACE: 4 x Gigabit PoE+ Ports; 1 Gigabit SFP Slot; 6-Pin Removable Terminal Block; DIN-Rail Mount; LED Indicators; Wall Mount; Grounding Point
- POE+ POWER & SWITCHING CAPACITY: The industrial PoE+ switch is equipped with 10Gbps switching capacity, and a 120W @56V DC PoE power budget supplies up to four Power over Ethernet devices with PoE+ power.
- DIN-RAIL & WALL MOUNT KIT: This 5-Port Gigabit PoE+ switch comes with an integrated DIN-Rail mount and mounting hardware brackets.
- WIDE TEMPERATURE SWITCH: The metal hardened IP30 rated DIN-Rail Gigabit PoE+ switch is equipped with a rugged IP30 rated enclosure and designed to withstand a wide temperature range 20° - 65°C (-4° - 149°F) for harsh environments.
- REDUNDANT POWER: The 5-port network switch has dual redundant power inputs with overload current protection (powersupply sold separately: models:TI-S12048 / 48VDC3000)
- ALARM RELAY: The DIN-Rail switch alarm output is triggered by power failure of primary and/or redundant power
- TRENDnet LIFETIME PROTECTION: The TI-PGM541 Industrial Gigabit PoE+ Switch comes with Lifetime TRENDnet Manufacturer Protection.
TRENDnet's 5-Port Industrial Gigabit PoE+ DIN-Rail Switch -20° - 65°C (-4° - 149°F), model TI-PGM541, has four gigabit PoE+ ports with a 120W PoE power budget, plus one gigabit SFP slot for long distance fiber applications. Users are able to connect four PoE+ devices to the switch, while still providing one gigabit SFP slot for an additional network connection. This switch is equipped with an IP30 rated metal enclosure, designed to operate within a wide temperature range of -20° - 65°C (-4° - 149°F) for harsh, industrial environments.
PoE Power
A 120W PoE+ power budget supplies up to four Power over Ethernet devices with PoE+ power.
Fault Tolerance
Features redundant power inputs with overload current protection and output alarm relay.
Industrial Hardened Design
Rugged IP30 rated housing is designed to operate within a wide temperature range of -20° - 65°C (-4° - 149°F).
NETWORKING SOLUTION | FEATURES | Full PoE+ Power Budget
Supplies up to 30W of PoE/PoE+ power per port with a 120W PoE power budget
Switching Capacity
10Gbps switching capacity
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 9KB), for increased performance
Network Ports
4 x Gigabit PoE+ ports and 1 x Gigabit SFP slot
Redundant Power
Redundant power inputs with overload current protection (
Power supply sold separately (models: TI-S15052, TI-S24052, TI-S12048)
Wide Operating Temperature
Rated for an operating temperature range of -20° - 65°C (-4° - 149°F)
DIN-Rail/Wall Mounts
IP30 rated metal enclosure with included DIN-Rail and wall-mount hardware
Alarm Relay
Alarm relay triggered by power failure of primary and/or redundant power
Grounding Point
Grounding point protects equipment from external electrical surges
NDAA / TAA compliant (U.S. and Canada only)
Detailed Specs
