Ubiquiti Networks AF11-COMPLETE-HB Data Networking

Ubiquiti Networks - Ubiquiti airFiber 11 AF-11 1.20 Gbit/s Wireless Access Point - 5 GHz - MIMO Technology - 1 x Network (RJ-45) - Gigabit Ethernet.
DUE TO GLOBAL MANUFACTURE SUPPLY CHAIN ISSUES, EXPECT EXTENDED LEAD TIMES FOR UBIQUITI PRODUCTS.

Create a reliable wireless business network with this wireless access point that features a high-speed data transfer rate
1.20 Gbit/s wireless transmission speed provides high and efficient communication with maximum efficiency
Up to 10x faster than standard Ethernet connectivity for your wired network
Management port for convenient and more powerful connectivity
The device is capable of obtaining power from the PoE source itself. Bye bye power lines and outlets!

Need a different version? See all Ubiquiti Networks Parts Accessories

Chat Now for Qty Discount

Add to Quote

$2,109.95

Ubiquiti Networks AF11-COMPLETE-HB Data Networking

Detailed Specs

Technical Information

Frequency Band:

5 GHz

Wireless Transmission Speed:

1.20 Gbit/s

MIMO Technology:

Yes

Interfaces/Ports

Ethernet Technology:

Gigabit Ethernet

Number of Network (RJ-45) Ports:

PoE PD Port:

Yes

Management Port:

Yes

Physical Characteristics

Height:

12.9"

Width:

4.4"

Depth:

3.4"

Weight (Approximate):

4.98 lb

Miscellaneous

Package Contents:

airFiber 11 AF-11 Satellite Radio
50V, 1.2A PoE Gigabit Adapter
1 x High-band Duplexer

Additional Information:

Networking Interface:

Data: 1 x 10/100/1000 Ethernet Port
Management: 1 x 10/100 Ethernet Port

Mounting: AF-11G35 Mount Compatible
Supported Voltage Range: 38-56VDC
Power Supply: UniFi PoE Switch
Operating Temperature: -40 to 55° C (-40 to 131° F)
RF Connectors: 4 x SMA Weatherproof, Two per Chain: TX 0, RX 0 (Chain 0) and TX 1, RX 1 (Chain 1) (2) N-Type Waterproof, One per Duplexer

SYSTEM

Processor: INVICTUS™ 2 IC
Maximum Throughput: 1.2+ Gbps
Encryption: 128-bit AES
OS: airOS F
Wireless Modes: SISO/MIMO
Operating Frequency: 10.7-11.7 GHz (Depends on Regulatory Region)
Max. Conducted TX Power: 30 dBm (Depends on Regulatory Region)
Frequency Accuracy: ± 1 ppm
Channel Bandwidth:

3.5/5/7/10/14/20/28/30/40/50/56 MHz
Selectable
Programmable Uplink and Downlink Duty Cycles

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
REACH

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0817882026932

UPC: 817882026932

EAN: 0817882026932

UNSPSC: 43222631

Reviews

Q&A

Get help from a Barcoding Expert!

The Ubiquiti Networks AF11-COMPLETE-HB Data Networking is also known as UBI-AF11COMPLETEHB
