Zebra DS8178-HCBU210FS5W Barcode Scanner

Zebra DS8178-HC - Healthcare Scanners, Zebra DS8178-HC, DS8178-HC FIPS Desk/Wall Cradle (With Fasteners) USB Kit: DS8178-HCMF00BVMWW Scanner, CBA-U21-S07ZBR Shielded USB Cable, CR8178-SC100FBWW Cradle, FAST-PC0081W-Q1 Fasteners
Connectivity
Corded
Form Factor
Handheld
Interface Options
USB
Scanner Capability
1D
Scanner Type
Imager
  • At a low cost, it gives more control by manual scanning, thus adds to the effectiveness and profitability
  • Allows productive and precise reading of 1D barcodes
  • Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
  • LED aimer is a perfect choice for patient-facing applications
  • Increase productivity and performance by excluding the cable
  • Bluetooth technology - Allows compatibility with most of your smart devices
Read More
$963.87
In Stock
3-year Premium Plus ($138.50)
3-year Premium ($89.00)
No Support
Add to Quote
Zebra DS8178-HC Barcode Scanner Model Overview
The DS8108-HC offers unparalleled protection against the spread of bacteria with the highest disinfectant wipe down capability in the industry. The housing and connectors are designed to withstand the harshest of wipe down solutions. The green LED aimer is easy on the eyes and can be used in NICUs where laser aimers are not advised. The DS8108-HC’s built-in lamp can illuminate a nurse’s workspace, so there’s no need to disturb sleeping patients by turning on the room lights.

Key Features:
  • Only the DS8100-HC Series combines the power of an 800 MHz microprocessor, a high-resolution megapixel sensor and Zebra’s exclusive PRZM Intelligent Imaging technology. With this unique combination of hardware and advanced algorithms, the DS8100-HC Series instantly captures the most problematic barcodes found in pharmacies, labs and at the point-of-care — including dense, tiny, curved, poorly printed, shiny, crinkled, faded, distorted, dirty or damaged, as well as electronic barcodes on dimly lit displays.
  • Only the DS8100-HC Series offers a purpose-built housing specially designed to help prevent the spread of bacteria. Special plastics allow for safe wipe-downs with the widest selection of the harshest and most aggressive disinfectants used in today’s hospitals. And concealed screw holes and seams eliminate areas where bacteria could hide — even after a wipedown.
  • Choose from a wide array of easily controllable feedback modes designed for virtually any hospital environment — from the Intensive Care Unit to a quiet night shift or a busy day shift. Staff can choose between haptic/vibration, a good decode LED, a traditional beep tone with adjustable volume and frequency, and Zebra’s Direct Decode Indicator that projects the illumination on the barcode to confirm that it has been captured. In Night Mode, a quick press of the trigger toggles between an audible beep and vibration. Clinicians can be confident that a medicine, specimen or IV bag was properly scanned — without disturbing patients or interrupting the workflow to look at the scanner.
  • Thanks to a highly visible and safe LED aimer, the DS8100-HC Series can be used in the NICU where the use of laser aimers is not advised. And the green aimer reduces the likelihood of triggering PTSD episodes.
  • Two interchangeable power options are available to power your devices: a PowerPrecision+ battery or a PowerCap capacitor. You can swap power options at any time on all models, right in your facility — no need to purchase separate battery-free and battery powered devices. And since the PowerPrecision+ battery and PowerCap capacitor can report their model and serial numbers, you’ll always know which power source is in each scanner. On a single charge, the advanced PowerPrecision+ battery provides over three around-the-clock days of continuous scanning, plus a wealth of metrics for better battery management. The PowerCap capacitor is ideal when the scanner can always be inserted into a charging cradle when not in use. The largest capacitor in its category, the superior PowerCap offers 2,000 scans on a full charge and 100 scans after as little as 35 seconds in the cradle — both metrics are four times greater than competitive scanners.


Applications:

  • Patient ID verification
  • Medication administration
  • Specimen collection and lab delivery
  • Pharmacy: medication intake and inventory
  • Operating Room: surgical supply instruments and implants
  • Electronic record access
  • Dietary management
  • Chain of custody of controlled substances
Zebra DS8178-HCBU210FS5W Barcode Scanner Overview

TTER WORKFLOWS FOR HEALTHCARE PROFESSIONALS. BETTER EXPERIENCES FOR PATIENTS.

As a healthcare provider, you need to deliver the very best in care, every second of every day. That means giving your healthcare professionals the tools they need to improve patient outcomes, increase productivity and streamline everyday processes. With the purpose-built DS8100-HC, you can. With the ability to instantly capture the most difficult to read barcodes; an industry-first housing that offers maximum protection against the spread of bacteria; Night Mode with Vibrate for can't miss feedback on decodes and a built-in lamp, the DS8100-HC can seamlessly integrate into existing healthcare workflows to boost process efficiencies and ensure that patients are left undisturbed until necessary. Combined with Zebra's complimentary manageability tools to simplify the setup, deployment, performance monitoring and ongoing management of your scanners, the DS8100-HC is the ideal solution to enhance patient safety, the productivity of staff members and the efficiency of point-of-care operations.

IMPROVED PATIENT EXPERIENCES

Unparalleled Performance on Virtually Every Barcode in Any Condition
Only the DS8100-HC Series combines the power of an 800 MHz microprocessor, a high-resolution megapixel sensor and Zebra's exclusive PRZM technology. With this unique combination of hardware and advanced algorithms, the DS8100-HC Series instantly captures the most problematic barcodes found in pharmacies, labs and at the point-of-care - including dense, tiny, curved, poorly printed, hiny, crinkled, faded, distorted, dirty or damaged, as well as electronic barcodes on dimly lit displays.

First-of-its-kind Housing Offers Maximum Protection Against the Spread of Infection
Only the DS8100-HC offers a purpose-built housing specially designed to help prevent the spread of bacteria. Special plastics allow for Safe wipe-downs with the widest selection of the harshest and most aggressive disinfectants used in today's hospitals. And concealed screw holes and seams eliminate areas where bacteria could hide - even after a wipedown.

Flexible User-Selectable Feedback Including Night Mode with Vibrate
Choose from a wide array of easily controllable feedback modes designed for virtually any hospital environment. From the Intensive Care Unit to a quiet night shift or a busy and more noisy day shift, there is a feedback mode that will instantly notify your healthcare workers that a barcode was properly captured - without disturbing patients.

In addition to the standard LED, vibrate and beeper feedback, Zebra's Direct Decode Indicator flashes illumination onto the barcode to confirm that it has been captured. Clinicians can be confident that a medicine, specimen or IV bag was properly scanned - without interrupting the work flow to look at the scanner.

With Night Mode, healthcare workers can switch between vibrate and beeper feedback by simply depressing the trigger for a few seconds.

And it's easy to control it all. Enable vibrate, beeper and the Direct Decode Indicator individually or in any combination, and easily adjust beeper volume, beeper frequency and illumination intensity.

Patient Safety
The DS8100's green aiming spot avoids blue wavelengths, which can potentially cause eye injury.

ADAPTABLE TO CLINICIAN WORKFLOWS
Continuous 24 Hour Scanning
With Zebra's exclusive PowerPrecision+ smart battery in the cordless DS8178-HC, your nurses and workers will always have the power they need for the busiest shift. Devices are always available - no need for charging mid-shift.

Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D

  • Code 39
  • Code 128
  • Code 93
  • Codabar/NW7
  • Code 11
  • MSI
  • Plessey
  • UPC/EAN
  • I 2 of 5
  • Korean 3 of 5
  • GS1 DataBar
  • Base 32(Italian Pharma)
2D
  • PDF417
  • Micro PDF417
  • Composite Codes
  • TLC-39
  • Aztec
  • DataMatrix
  • MaxiCode QR Code
  • Micro QR
  • Chinese Sensible(Han Xin)
  • Postal Codes
Light Source:
LED
Image Sensor Type:
Imager
Network & Communication
Bluetooth:
Yes
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Form Factor:
Handheld
Product Color:
Healthcare White
Height:
6.6"
Width:
2.6"
Depth:
4.2"
Weight (Approximate):
8.30 oz
Miscellaneous
Package Contents:
  • DS8178-HC Handheld Barcode Scanner
  • Standard Cradle
  • Presentation Cradle
  • Spare Battery
  • Document Capture Stands
Environmentally Friendly:
Yes
Country of Origin:
Mexico
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0005698257484
UPC: 005698257484
EAN: 0005698257484
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Zebra DS8178-HCBU210FS5W Barcode Scanner is also known as ZEB-DS8178HCBU210FS5 or DS8178HCBU210FS5W.
